374 SERVICING AND MAINTENANCE
3. Lift the engine air cleaner filter cover to
access the engine air cleaner filter.
Engine Air Cleaner Filter Assembly
4. Remove the engine air cleaner filter from
the housing assembly.
Engine Air Cleaner Filter Installation
NOTE:
Inspect and clean the housing assembly if dirt
or debris is present before replacing the engine
air cleaner filter.
1. Install the engine air cleaner filter into the
housing assembly with the engine air
cleaner filter inspection surface facing
downward.
2. Install the engine air cleaner filter cover
onto the housing assembly locating tabs.
3. Install screws to secure the engine air
cleaner filter cover to the housing assembly
and reconnect the electrical connector
(if equipped).
ACCESSORY DRIVE BELT INSPECTION
When inspecting accessory drive belts, small
cracks that run across ribbed surface of belt
from rib to rib, are considered normal. These
are not a reason to replace belt. However,
cracks running along a rib (not across) are not
normal. Any belt with cracks running along a rib
must be replaced. Also have the belt replaced if
it has excessive wear, frayed cords or severe
glazing.
1— Engine Air Cleaner Filter
WARNING!
Do not attempt to inspect an accessory
drive belt with the vehicle running.
You can be badly injured working on or
around a motor vehicle. Only do service
work for which you have the knowledge and
the proper equipment. If you have any
doubt about your ability to perform a
service job, take your vehicle to a compe-
tent mechanic.
