3 MACHINE SIGNALS AND CONTROLS
3.1 Main switchboard
Figura 1
Ref. Descrizione
1
SLIM
2
BATTERY LEVEL AND CONTROLLER MDI ALARM
3
START/LOCAL/REMOTE SWITCH
4
BY-PASS
5
LIFTING
6
TELESCOPE
7
WINCH
8
EMERGENCY PUSH BUTTON
1
2
3
4
5 6 7
8
