Pagina 30 di 47
5–USE OF THE MACHINE IN
REGULAR WORKING CO NDITIONS
_____________________________________________________________________________________________
5.5 Alarm
If necessary on the display w ill appear a flashing alarm code to help you abaut machine w orking
conditon.
ALLARM / WARNING ACTION
02- Block due to boom minimu
angle → Boom up
03- Block due to boom max angle → Boom dow
04- Block due to boom minimum exstension → Telescope out
05- Block due to boom
ax exstension → Telescope in
08- Back side pressure transducer disconnected → Check pressure transducer w iring
09- Back side pressure transducer short
circuited → 1° Check fuses >2° replace it
10- Rod side pressure transducer disconnecte
→ Check pressure transducer w iring
11- Rod side pressure transducer shor
-circuite
→ 1° Check fuses >2° replace it
80- Up/dow n boom lever disconnected → Check w iring
81- Up/dow n boom lever short-circuited → Check fuses
82- Telescope in/out lever disconnected → Check w iring
83- Telescope in/out lever short-circuited → Check fuses
84-
ope up/dow n lever disconnected → Check w iring
85- Rope up7dow n lever short-circuited → Check fuses
22- Emergency push button held dow
→ Reset the machine emergency push
button
30- By pass o
62- Radio Remote Control off → Turn on radio remote control or turn key
sw itch to LOCAL position
90- Block due to rope up → Unw ind the rope or telescope in
91- Block due to rope dow
→ Wind the rope
120- Canbus Timeout ACQ → Call service
121- Guasto interno scheda ACQ → Call service
LARM: 62
