JEKKO MPK20 - Main Part

Pagina 24 di 47
4-MAIN PART
_
___________________________________________________________
_
_
________________________________
4 MAIN PART
Ref. Description
1
Winch
2
Pulley system
3
Counte
r
-
weight
4
Signal light
s
5
Switchboard
6
Motor and electric compartment
7
Switchboard
8
Battery compartment
9
Free compartment
1
2
3
4
5
7
6
8
9
