<E§0
VM9313
I
Table 2:
Video
Output
Modes
Setting
Table 2 shows the video output mode for each playing
source.
Aspect Ratio
Press the WIDE button (28) on the remote control
or
WIDE
button (2) on the monitor to adjust the aspect ratio as follows:
Parking
Brake
Inhibit
Table 3:
Monitor
Protective
Measures
When the pink "Parking" wire is connected to the vehicle
Parking Brake circuit, the front TFT monitor will display video
when the Parking Brake is engaged. (When the pink wire is
grounded via the Parking Brake circuit, video will be
displayed.)
Monitor
Movement
Mechanism
If
an
obstruction occurs in the monitor path, the following
protective measurements can be executed to prevent
damage to the mechanism
or
monitor:
Obstruction
Self
OPEN
Butlon Power
Protection
Pressed
Reconnected
Monitor
Monitor is Monitor fully Monitor is
loading out automati-
extended
automati-
horizontally cally loaded horizontally cally loaded
into unit into unit
Monitor Unit stops
at
Monitor fully Monitor is
loading in
obstruction extended 'automati-
horizontally point horizontally
cally loaded
into unit
Monitor Unit stops
at
Monitor Monitor swiv-
loading out obstruction swivels back els back to
vertically point to the unit the unit
Monitor Unit stops
at
Monitor Monitor swiv-
loading in obstruction swivels back
els back to
vertically
point to the unit the unit
After the protective procedure is executed, normal operation
is resumed by pressing the OPEN button (4) or disconnecting
and reconnecting the power.
FULL
The entire screen is extended
horizontally to the aspect ratio
of
16 to
9.
The extension ratio is the same at
any point.
NORMAL
The conventional display image has a
4 to 3 ratio
of
horizontal to vertical,
leaving a blank area on the right and
left sides
of
the display.
F01
~
Playing Source
Video Output Modes
AM/FM TUNER
RGB Mode
SAT TUNER RGB Mode
iPod RGB Mode
DVD RGB Mode
AUXIN
CVBS Mode
·CVBS
- Composite Video Baseband Signal
ParameterAdjustment Procedure
1.
Enter
Quality
Setting
Mode:
Press the PIC button (24) on the remote control
or
the
PICIBAND button (3) on the monitor.
2.
Select
Item
to
Set:
Press the AUDIO button (5) on the control panel to
select
"BRIGHr
or
"CONTRAST".
3.
Set
Parameters:
Press the
+/-
buttons (15, 16) on the remote
or
tum the
AUDIO control (5) on the control panel.
4.
Exit
Quality
Setting
Mode:
Press the PIC button (24) on the remote control
or
the
PICIBAND button (3) on the monitor
USING
THE
TFT
MONITOR
Open/Close
TFT
Monitor
Open
TFT
Monitor
Press the OPEN button (4) on the front panel
or
press the
(
..
"\,)
button (25) on the remote control to activate the
mechanism that moves the display panel into the viewing
position.
Close TFT Monitor
Press the OPEN button (4) on the front panel or press the
(
........
) button (25) on the remote control to load the display
panel back into the compartment.
TFT
Monitor
Auto
Open
If"TFT
Auto Open" is "on" when the unit is tumed on, the
monitor automatically moves to the viewing position.
If
"TFT Auto Open" is "off' when the unit is turned on, press
the OPEN button (4)
or
(
..
"\,)
button (25) on the remote
control to move the monitor into the viewing position.
If
"TFT Auto Open" is set to "Manual", the TFT will not close
when the key is turned off.
Monitor
Tilt
Angle
Adjustment
A known characteristic
of
LCD panels is the quality
of
the
display in relationship to the viewing angle. The monitor
angle can be adjusted for optimum viewing using one of the
following methods:
Step
by
Step Angle
Adjustment
Press the (
~
) or ( ¥ )button on the remote control to adjust
the tilt angle
of
the screen one step at a time.
Continuous Angle
Adjustment
Press
and
hold the (
~
)
or
( ¥ )button on the remote control
to adjust the tilt angle in a continuous motion.
7
