PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 72
Imax Alarm
This alarm is raised when there is a current draw above 33A per channel. When operating under
parallel or redundant mode, the alarm is raised when the current draw is above 66A per boost
brick. Reduce the current to clear the alarm.
Pmax Alarm
This alarm is raised when there is power output over 2200W per channel. When operating under
parallel or redundant mode, the alarm is raised when the power output is above 4400W per
boost brick. Reduce the power load to clear the alarm.
Vmax Alarm
This alarm is raised when the output voltage is above 70V per module. Reduce the voltage to
clear the alarm.
S Boost Pos Error
A positioning error occurred. If the configuration file uses less number of channels and an
additional module is plugged in without updating the configuration, the system will flag this
alarm. To reset the alarm, select the correct configuration file and reset the Orion controller by
withdrawing it for a few seconds, then re-insterting.
S Boost Power Limit
Event indicating that at least one of the configured boost convertors is in power limit.
Orion controller fail (failure message or blank screen)
This is the result of a failed controller.
1. Remove the controller according to the steps in Section 3.4.
2. Reinsert the controller.
3. If the controller is still faulty, replace the controller.
Storage out of memory
Currently the device logs 10000 events per file up to 90 different files. If the device history is
not cleared, the system will generate this alarm.
S Boost Skipped Message
• Indicates that there is an issue with the Raycap OVP telemetry (RS485) data reaching (or
not reaching) the PB “VBOOST IN” port.
• PB-COM LED steady red indicates a fault or error in the message from the Raycap OVP or
a bad connection to communication board.
