56
Table8-11 Loading matching set
Para Set
Explain
U-Rated
Motor rated voltage (V), which should be set according to pump
nameplate.
I-Rated
Motor rated current (A), which should be set according to pump
nameplate.
P-Rated
Motor rated power (w), which should be set according to pump
nameplate.
F-Rated
Motor rated frequency (Hz), which should be set according to
pump nameplate.
RPM-Rated
Motor rated rotate speed (rpm), which should be set according to
pump nameplate.
PF-Rated
Motor rated rotate speed (rpm), which should be set according to
pump nameplate.
Imotor
The pump motor over-load protection value when over-load,
please refer to the rated current of motor to set this parameter,
which should match motor over-load capacity, recommended to
equal the rated current of motor.
StopFreq
Stop frequency (Hz). Setting principle is stop frequency when
minimum flow is output.
M-Mode
If water output is abnormal, and caused by reversed motor phase
sequence, you can try to reset this model from “REV” to
“FWD”.Default is “FWD”.
DebugMode
This item indicate the running model of inverter:
=0 Vector current control model;
=1 Vector voltage control model;
