4. For more details on a particular item, select the item and press Enter. The
Focus page for the item appears. Figure 23 is an example for the Occupancy
Schedule.
5. Use the up/down arrow keys to navigate through the information.
6. Press Esc to return to the Main Menu.
Commanding Configured Parameters and Setpoints
To command configured parameters and setpoints:
1. Go to the Main Menu.
2. Select the Parameter/Setpoints option. A list of all configured parameters and
setpoints appears.
3. Use the up/down arrow keys to select the parameter or setpoint (for example,
analog or binary) that you want to command.
4. Press Enter. The Focus page for the item appears with the Command option
selected.
5. Press Enter to display the commands available to this parameter or setpoint.
Figure 24 shows an example for the Command Pages.
OCC-SCHEDULE
Cancel
Command
Reliability
FIG:OccSch
Out of Service
Occupied
False
Reliable
Figure 23: Occupancy Schedule Page
Command
Release
Adjust
Override
FIG:CmdS el
Figure 24: Command Page
