Technical Specifications
FX-DIS Local Controller Display
Product Code Number FX-DIS1710-0 Local Controller Display
Power Requirement Nominal 15 V Provided by Controller Over SA Bus
Power Consumption 2 VA Maximum
Ambient Operating Temperature 0C to 50C (32F to 122F)
Ambient Operating Conditions 10% to 90% RH, 30C (86F) Maximum Dew Point
Ambient Storage Temperature -40C to 70C (-40F to 158F)
Ambient Storage Conditions 5 to 95% RH, 30C (86F) Maximum Dew Point
Terminations RJ-12 6-Pin Jack at Service Port (Covered by Removable
Cap-Plug)
SA Bus Connection on Back of Unit
Processor Renesas® H8S-2398 32-bit Microprocessor
Memory 256 KB Flash Memory
8 KB Random Access Memory (RAM)
Operating System RTOS-H8S
Network and Serial Interfaces Communication to FX-PC Controller Over SA Bus
Graphic Display Resolution 240 pixels x 64 pixels with White LED Backlighting
(Adjustable)
Dimensions (Height x Width x Depth) 85.9 mm x 238 mm x 25.8 mm (3-3/8 in. x 9-3/8 in. x 1.0
in.)
Housing Plastic Housing Material: ABS + Polycarbonate
Protection: IP20 (IEC60529)
Mounting (Height x Width) Mount to the Outside of the Enclosure
70.5 mm x 216.5 mm (2-13/16 in. x 8-9/16 in.)
Compliance United States UL Listed, File E107041, CCN PAZX, UL 916, Energy
Management Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2
No. 205, Signal Equipment; Industry Canada Compliant,
ICES-003
Australia and
New Zealand
C-Tick Mark, Australia/NZ Emissions Compliant
Shipping Weight 0.14 kg (0.3 lb)
