FX-DIS Local Controller Display Technical Bulletin 25
Setting the Display Contrast
To set the display contrast:
1. Go to the Main Menu.
2. Scroll down to select the Controller Information option and press Enter.
3. Scroll down to select the Display Contrast parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a percentage for the
display contrast (Figure 32). The screen changes as you select a percentage.
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
Setting the Idle Timeout Value
To set the auto-logoff timeout value:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Idle Page Timeout parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a new idle timeout
value (Figure 33).
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
Figure 32: Modify Display Contrast Page
Modify
Accept
Cancel
Display Contrast
Selections
FIG:DsplyCntr
10%
50%
Current Setting
Modify
Accept
Cancel
Idle Page Timeout
Selections
F
I
G
:
I
d
l
t
m
e
o
u
t
5 min
1 Min.
Current Setting
Figure 33: Modify Idle Page Timeout Page
