FX-DIS Local Controller Display Technical Bulletin22
Idle Page
Timeout
Defines how long the
display waits between
keyboard interactions
before logging off the user.
1 minute, 5 minutes, 15 minutes,
30 minutes, 1 hour, No Timeout
Language Displays the configured
language.
(Not configurable)
Default: English (United States)
MAC Address Displays the controller’s
configured Media Access
Control (MAC) address.
(Not configurable)
Example: 22
MS/TP Baud
Rate
Displays the configured
Master-Slave/Token-
Passing (MS/TP) baud
rate.
(Not configurable)
Example: 38,400
Time Format
Preference
Sets how time of day
appears on the display.
12 MM (4:30)
12 MM SS (4:30:30)
12 MM AM/PM (4:30 PM)
12 MM SS AM/PM (4:30:30 PM)
24 MM (16:30)
24 MM SS (16:30:30)
1. Backlight intensity and display contrast both affect the readability of the display. Best visibility is
backlight intensity is Bright and display contrast is 10%. Worst visibility is backlight intensity is
off and display contrast is 90%.
Table 4: Display Information Preferences (Part 2 of 2)
Parameter Description Selections
