Johnson Controls GVB Series User Manual

Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
81
Operation
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Htg > Setup
ZT-ResetSpUpper (ZT Reset Setpoint
Upper)
deg F (61–131)
SF-DAT-SpHighThresh (Supply Fan
DAT Setpoint High Threshold)
% (0–100)
SF-DAT-SpLowThresh (Supply Fan DAT
Setpoint Low Threshold)
% (0–100)
HtgAdapTunEn (Heating Adaptive
Tuning Enable)
No, Yes
HtgOATCutout-Sp (Outside Air
Temperature Heating Cutout Setpoint)
deg F (0–100)
MornW-En (Morning Warm-Up Enabled) No, Yes
MornWRAT-Sp (Morning Warm-Up/
Return Air Temperature Setpoint)
deg F (50–85)
MornWDAT-Sp (Morning Warm-Up
Discharge Air Temperature Setpoint)
deg F (85–135)
HtgUnocc-En (Unoccupied Heating
Enabled)
No, Yes
HtgOcc-En (MZVAV Occupied Heating
Enabled)
No, Yes
DATTemper-En (Discharge Air
Temperature Tempering Enable)
No, Yes
DATTemper-Sp (Discharge Air
Temperature Tempering Setpoint)
deg F (40–60)
Htg > Service
> Unit
StgHtgCmd (Staged Heating Command) %
Htg-S (Heating Status)
OFF-Idle, ON, SAT Tempering, Morning Warm-
Up, Thermostat Heating, Unoccupied Heating,
Occupied Heating, OFF-Disabled, OFF-OAT
Lockout, OFF-SAT Limit, OFF-Waiting for
Changeover Delay, Comfort Ventilation
OprHtg-Sp (Operating Heating Setpoint) deg F
OprHtgDAT-SP (Operating Heating
Discharge Air Temperature Setpoint)
deg F
OprOAT (Operational Outside Air
Temperature)
deg F
OprZT (Operational Zone Temperature) deg F
RAT (Return Air Temperature) deg F
W1 - Thermostat OFF, ON
W2 - Thermostat OFF, ON
DAT (Discharge Air Temperature) deg F
HE-T (Heat Entering Temperature)
deg F
HET-Alarm (Heat Entering Temperature
Sensor Alarm)
Normal, Alarm
DATTempState (DAT Tempering State)
Disable, Enable
Htg > Service
> Stage 1–
Stage 8
H1-S (Heating Stage 1 Status)
OFF-Idle, ON-Minimum Runtime Timer, ON-Normal
Command, OFF-Heating is Disabled, OFF-Gas
Valve Lost Proof, OFF-Gas Valve False Proof,
OFF-Heating Limit Lockout, OFF-Anti-Short Cycle
Timer, OFF-Heating Stage is Disabled
