Johnson Controls LX Series User Manual

LX Series Unit Ventilator Controller User's Guide 103
SNVT_lev_percent (81)
SNVT_occupancy (109)
Table 44: SNVT_lev_percent
SNVT_lev_percent Description
SNVT Index 81
Measurement Percentage Level
Field Type Category Signed Long
Type Size 3 bytes
Valid Type Range -163.840 – 163.830
Type Resolution 0.005
Units Percent of full scale, or parts per million (ppm)
Invalid Value 32,767 (0x7FFF)
Raw Range -32,768 – 32,766
(0 x 8000 – 0 x 7FFE)
Scale Factor 5, -3, 0
S = a*10b*(R+c)
File Name N/A
Default Value N/A
Table 45: SNVT_occupancy
SNVT_occupancy Description
SNVT Index 109
Measurement occup_t
Field Type Category Enumeration
Type Size 1 byte
Valid Type Range occup_t
Type Resolution 1
Units N/A
Invalid Value OC_NUL
Raw Range occup_t
Scale Factor N/A
File Name SNVT_OC.H
Default Value N/A
