LX Series Unit Ventilator Controller User's Guide 85
Object Manage
The Object Manage screen enables you to view the status of the LONMARK object
and to use the LONMARK commands. To use the Object Manage screen, you must
configure the Unit Ventilator Controller and have it online and in communication
with the FX supervisory controller (Figure 40). Table 26 describes the parameters.
Object Status
Object Status messages are listed in the following sections with references to
tables describing the causes.
Table 25: Network Output Configuration Parameters
Field Description
Heartbeat The maximum time period between transmissions of the network
variable.
Send on Delta Enter the amount of change of the value of the network variable that
must occur before the variable is transmitted. The network variable is
transmitted whenever this much change occurs.
Throttle Enter the minimum time period that must pass before a network variable
is transmitted.
General The values entered in the General box affect all other network variables
not listed here.
Maximum Send Time Enter the maximum time between transmissions of network variables.
Minimum Send Time Enter the minimum time between transmissions of network variables.
Figure 40: Object Manage
