Johnson Controls LX Series - Snvt_Hvac_Status (112)

LX Series Unit Ventilator Controller User's Guide 99
SNVT_hvac_status (112)
Use for heating, ventilating, and air conditioning applications.
Table 35: SNVT_hvac_status
SNVT_hvac_status Description
SNVT Index 112
Measurement HVAC Status
Field Type Category Structure
Type Size 12 bytes
Table 36: SNVT_hvac_status Structure
Field Measurement
mode hvac_t
heat_output_primary signed long
heat_output_secondary signed long
cool_output signed long
econ_output signed long
fan_output signed long
in_alarm unsigned short
Table 37: HVAC Status Mode
HVAC Status Mode Description
Field mode
Measurement hvac_t
Field Type Category Enumeration
Type Size 1 byte
Valid Type Range hvac_t
Type Resolution 1
Units N/A
Invalid Value HV_NUL
Raw Range hvac_t
Scale Factor N/A
File Name SNVT_HV.H
Default Value N/A
