Johnson Controls LX Series User Manual

LX Series Unit Ventilator Controller User's Guide100
Table 38: Primary Heat Output
Primary Heat Output Description
Field Heat_output_primary
Measurement Primary Heat Output
Field Type Category Signed Long
Type Size 2 bytes
Valid Type Range -163.840 – 163.830
Type Resolution 0.005
Units Percent of full scale
Invalid Value 32,767 (0x7FFF)
Raw Range -32,768 – 32,766
0x7FFE
Scale Factor 5, -3, 0
S = a*10b*(R+c)
File Name N/A
Default Value N/A
Table 39: Secondary Heat Output
Secondary Heat Output Description
Field heat_output_secondary
Measurement Secondary Heat Output
Field Type Category Signed Long
Type Size 2 bytes
Valid Type Range -163.840 – 163.830
Type Resolution 0.005
Units Percent of full scale
Invalid Value 32,767 (0x7FFF)
Raw Range -32,768 – 32,766
0x7FFE
Scale Factor 5, -3, 0
S = a*10b*(R+c)
File Name N/A
Default Value N/A
