Johnson Controls LX Series User Manual

LX Series Unit Ventilator Controller User's Guide106
SNVT_temp_p (105)
SNVT_tod_event (128)
Table 52: SNVT_temp_p
SNVT_temp_p Description
SNVT Index 105
Measurement Temperature
Field Type Category Signed Long
Type Size 2 bytes
Valid Type Range -273.17 – 327.66
Type Resolution 0.01
Units Degrees Celsius
Invalid Value 32,767
(0x7FFF)
Raw Range -27,317 – 32,767
(0x8000 – 0x7FFE)
Scale Factor 1, 2, 0
S = a*10
b
*(R+c)
File Name N/A
Default Value N/A
Table 53: Occupancy Scheduling Event
Occupancy Scheduling Event Description
SNVT Index 128
Measurement Time of day event
Field Type Category Structure
Type Size 4 bytes
Table 54: SNVT_tod_event: Current State
SNVT_tod_event: Current State Description
SNVT Index Current_state
Measurement occup_t
Field Type Category Enumeration
Type Size 1 byte
Valid Type Range occup_t
Type Resolution 1
Units N/A
Invalid Value OC_NUL
Raw Range Occup_t
Scale Factor N/A
File Name SNVT_OC.H
Default Value N/A
