LX Series Unit Ventilator Controller User's Guide 105
Table 48: SNVT_switch Input Network Variable
Value (raw) State Two-State Interpretation
Any 0Off (0; 0)
0 1Off (0; 1)
> 0 1 On (200; 1)
Any -1 (0xFF) Invalid (no action)
Table 49: SNVT_switch Output Network Variable
Value (raw) State Two-State Interpretation
0 0Off
200 (0xC8) 1On
0 – 200
(0xC8) (any valid value)
-1
(0xFF)
Invalid (NULL)
Table 50: SNVT_switch Value
SNVT_switch Value Description
Field Value
Measurement Value
Field Type Category Unsigned Short
Type Size 1 byte
Valid Type Range 0 – 100
Type Resolution 0.5
Units Percent of full scale
Invalid Value N/A
Raw Range 0 – 100
(0 – 0xC8)
Scale Factor 5, -1, 0
S = a*10
b
*(R+c)
File Name N/A
Default Value N/A
Table 51: SNVT_switch State
SNVT_switch State Description
Field State
Measurement State
Field Type Category Signed Short
Type Size 1 byte
Valid Type Range 0-1
Type Resolution 1
Units N/A
Invalid Value -1 (0xFF)
Raw Range 0-1
Scale Factor 1, 0, 0
S = a*10
b
*(R+c)
File Name N/A
Default Value N/A
