Table 55: SNVT_tod_event: Next State
SNVT_tod_event: Next State Description
SNVT Index next_state
Measurement occup_t
Field Type Category Enumeration
Type Size 1 byte
Valid Type Range occup_t
Type Resolution 1
Units N/A
Invalid Value OC_NUL
Raw Range Occup_t
Scale Factor N/A
File Name SNVT_OC.H
Default Value N/A
Table 56: SNVT_tod_event: Time to Next State
SNVT_tod_event: Time to Next State Description
SNVT Index time_to_next_state
Measurement Time to next state
Field Type Category Unassigned long
Type Size 2 bytes
Valid Type Range 0 – 65,535
Type Resolution 1
Units Minute of hour
Invalid Value N/A
Raw Range 0 – 65,535
(0 – 0xFFFF
Scale Factor 1, 0, 0
S = a*10b*(R+c)
File Name N/A
Default Value N/A
