Table 27: Cool multiplier furnace - 2.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
Z8ES100C20LMPS1 XAHC36D 1.01 0.96 0.96
Z8ES100C20SMPS1S XAFC30C 0.99 0.91 0.92
Z8ES100C20SMPS1S XAFC36D 0.99 0.90 0.92
Z8ES100C20SMPS1S XAHC30C 0.99 0.91 0.92
Z8ES100C20SMPS1S XAHC36D 1.01 0.96 0.96
Z8ES120C16LMPS1 XAFC30C 0.99 0.94 0.93
Z8ES120C16LMPS1 XAFC36D 0.99 0.90 0.92
Z8ES120C16LMPS1 XAHC30C 0.99 0.92 0.92
Z8ES120C16LMPS1 XAHC36D 0.99 0.91 0.92
Z8ES120C16SMPS1S XAFC30C 0.99 0.94 0.93
Z8ES120C16SMPS1S XAFC36D 0.99 0.90 0.92
Z8ES120C16SMPS1S XAHC30C 0.99 0.92 0.92
Z8ES120C16SMPS1S XAHC36D 0.99 0.91 0.92
Z8ES120C20LMPS1 XAFC30C 0.99 0.91 0.92
Z8ES120C20LMPS1 XAFC36D 1.02 1.00 0.98
Z8ES120C20LMPS1 XAHC30C 1.01 1.02 0.97
Z8ES120C20LMPS1 XAHC36D 1.02 1.00 0.98
Z8ES120C20SMPS1S XAFC30C 0.99 0.91 0.92
Z8ES120C20SMPS1S XAFC36D 1.02 1.00 0.98
Z8ES120C20SMPS1S XAHC30C 1.01 1.02 0.97
Z8ES120C20SMPS1S XAHC36D 1.02 1.00 0.98
Z8ET080B12LMPS1S XAFB30C 0.99 0.95 0.93
Z8ET080B12LMPS1S XAFB36D 0.99 0.93 0.93
Z8ET080B12LMPS1S XAFC30C 0.99 0.95 0.93
Z8ET080B12LMPS1S XAFC36D 0.99 0.93 0.93
Z8ET080B12LMPS1S XAHB30C 0.99 0.95 0.93
Z8ET080B12LMPS1S XAHC30C 0.99 0.95 0.93
Z8ET080B12LMPS1S XAHC36D 0.99 0.93 0.93
Z8ET080B12LMPS1S XAUB30C 0.99 0.95 0.93
Z8ET080B12LMPS1S XAUB36D 0.99 0.93 0.93
Z8ET080C16LMPS1S XAFC30C 1.01 0.98 0.95
Z8ET080C16LMPS1S XAFC36D 1.01 0.96 0.95
Z8ET080C16LMPS1S XAHC30C 1.01 0.98 0.95
Z8ET080C16LMPS1S XAHC36D 1.01 0.96 0.95
Z8ET100C16LMPS1S XAFC30C 0.99 0.91 0.92
Z8ET100C16LMPS1S XAFC36D 0.99 0.89 0.92
Z8ET100C16LMPS1S XAHC30C 0.99 0.90 0.92
Z8ET100C16LMPS1S XAHC36D 0.99 0.89 0.92
Z8ET100C20LMPS1S XAFC30C 1.02 1.03 0.96
Z8ET100C20LMPS1S XAFC36D 1.02 1.00 0.96
Z8ET100C20LMPS1S XAHC30C 1.02 1.02 0.96
Z8ET100C20LMPS1S XAHC36D 1.02 1.00 0.96
Z8ET120C20LMPS1S XAFC30C 0.99 0.95 0.95
Z8ET120C20LMPS1S XAFC36D 0.99 0.93 0.95
Z8ET120C20LMPS1S XAHC30C 0.99 0.95 0.95
Z8ET120C20LMPS1S XAHC36D 0.98 0.91 0.94
Performance data - 3 ton
See the following tables for performance and multiplier data for the TCD2B36S21S unit.
