Johnson Controls TCD2B18S21S User Manual

Furnace capacity - 1.5 ton
Table 7: Furnace capacity - 1.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B18S21S TL8E060A12UH11 14.5 XAFA18A 675 18.00 13.50 14.25 12.00
TCD2B18S21S TL8E060A12UH11 14.5 XAFA24B 675 18.00 13.60 14.25 12.00
TCD2B18S21S TL8E060A12UH11 17.5 XAFB18A 700 17.90 13.60 14.25 12.00
TCD2B18S21S TL8E060A12UH11 17.5 XAFB24B 700 18.00 13.70 14.50 12.25
TCD2B18S21S TL8E060A12UH11 14.5 XAHA18A 675 18.00 13.50 14.00 11.75
TCD2B18S21S TL8E060A12UH11 14.5 XAHA24B 675 18.00 13.60 14.50 12.25
TCD2B18S21S TL8E060A12UH11 17.5 XAHB24B 700 17.90 13.70 14.25 12.00
TCD2B18S21S TL8E060A12UH11 14.5 XAUA18A 675 18.00 13.50 14.25 12.00
TCD2B18S21S TL8E060A12UH11 14.5 XAUA24B 675 18.00 13.60 14.25 12.00
TCD2B18S21S TL9E060B12UH11 17.5 XAHB24B 500 17.80 12.20 14.25 12.00
TCD2B18S21S TM8E040A12MP11 14.5 XAFA18A 700 18.00 13.70 14.25 12.00
TCD2B18S21S TM8E040A12MP11 14.5 XAFA24B 550 17.90 12.60 14.25 12.00
TCD2B18S21S TM8E040A12MP11 17.5 XAFB18A 725 17.90 13.70 14.25 12.00
TCD2B18S21S TM8E040A12MP11 17.5 XAFB24B 725 17.90 13.80 14.50 12.25
TCD2B18S21S TM8E040A12MP11 14.5 XAHA18A 700 18.00 13.70 14.25 12.00
TCD2B18S21S TM8E040A12MP11 14.5 XAHA24B 550 18.00 12.70 14.50 12.25
TCD2B18S21S TM8E040A12MP11 17.5 XAHB24B 575 17.90 12.80 14.25 12.00
TCD2B18S21S TM8E040A12MP11 14.5 XAUA18A 700 18.00 13.70 14.25 12.00
TCD2B18S21S TM8E040A12MP11 14.5 XAUA24B 550 17.90 12.60 14.25 12.00
TCD2B18S21S TM8E060A12MP11 14.5 XAFA18A 625 18.00 13.20 14.25 12.00
TCD2B18S21S TM8E060A12MP11 14.5 XAFA24B 625 18.00 13.20 14.50 12.25
TCD2B18S21S TM8E060A12MP11 17.5 XAFB18A 575 18.00 12.80 14.50 12.25
TCD2B18S21S TM8E060A12MP11 17.5 XAFB24B 725 18.00 13.90 14.75 12.25
TCD2B18S21S TM8E060A12MP11 14.5 XAHA18A 700 18.00 13.70 14.00 11.75
TCD2B18S21S TM8E060A12MP11 14.5 XAHA24B 600 18.00 13.10 14.25 12.00
TCD2B18S21S TM8E060A12MP11 17.5 XAHB24B 625 18.00 13.20 14.75 12.25
TCD2B18S21S TM8E060A12MP11 14.5 XAUA18A 625 18.00 13.20 14.25 12.00
TCD2B18S21S TM8E060A12MP11 14.5 XAUA24B 625 18.00 13.20 14.50 12.25
TCD2B18S21S TM8E080B12MP11 17.5 XAFB18A 725 18.00 13.90 14.25 12.00
TCD2B18S21S TM8E080B12MP11 17.5 XAFB24B 525 18.00 12.50 14.50 12.25
TCD2B18S21S TM8E080B12MP11 17.5 XAHB24B 525 18.00 12.50 14.50 12.25
TCD2B18S21S TM8E100B12MP11 17.5 XAFB18A 650 18.00 13.30 14.50 12.25
TCD2B18S21S TM8E100B12MP11 17.5 XAFB24B 650 18.00 13.40 14.75 12.25
TCD2B18S21S TM8E100B12MP11 17.5 XAHB24B 625 18.00 13.20 14.50 12.25
TCD2B18S21S TM8V060A12MP12C 14.5 XAFA18A 650 18.00 13.30 14.25 12.00
TCD2B18S21S TM8V060A12MP12C 14.5 XAFA24B 575 17.90 12.80 14.25 12.00
TCD2B18S21S TM8V060A12MP12C 17.5 XAFB18A 650 18.00 13.30 14.50 12.25
TCD2B18S21S TM8V060A12MP12C 17.5 XAFB24B 650 17.90 13.30 14.50 12.25
TCD2B18S21S TM8V060A12MP12C 14.5 XAHA18A 650 18.00 13.40 14.25 12.00
TCD2B18S21S TM8V060A12MP12C 14.5 XAHA24B 650 18.00 13.40 14.25 12.00
TCD2B18S21S TM8V060A12MP12C 17.5 XAHB24B 650 18.00 13.40 14.50 12.25
TCD2B18S21S TM8V060A12MP12C 14.5 XAUA18A 650 18.00 13.30 14.25 12.00
TCD2B18S21S TM8V060A12MP12C 14.5 XAUA24B 575 17.90 12.80 14.25 12.00
TCD2B18S21S TM8V080B12MP12C 17.5 XAFB18A 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8V080B12MP12C 17.5 XAFB24B 625 18.00 13.30 14.50 12.00
TCD2B18S21S TM8V080B12MP12C 17.5 XAHB24B 625 18.00 13.30 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 14.5 XAFA18A 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 14.5 XAFA24B 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 17.5 XAFB18A 625 17.90 13.10 14.25 12.00
TCD2B18S21S TM8Y060A12MP11 17.5 XAFB24B 650 18.00 13.40 14.75 12.25
TCD2B18S21S TM8Y060A12MP11 14.5 XAHA18A 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 14.5 XAHA24B 550 18.00 12.70 14.50 12.25
TCD2B18S21S TM8Y060A12MP11 17.5 XAHB24B 625 17.90 13.20 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 14.5 XAUA18A 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8Y060A12MP11 14.5 XAUA24B 625 18.00 13.20 14.00 11.75
TCD2B18S21S TM8Y080B12MP11 17.5 XAFB18A 650 18.00 13.30 14.50 12.25
TCD2B18S21S TM8Y080B12MP11 17.5 XAFB24B 650 18.00 13.40 14.50 12.25
TCD2B18S21S TM8Y080B12MP11 17.5 XAHB24B 650 18.00 13.40 14.50 12.25
TCD2B18S21S TM9E026A08MP12 17.5 XAFB24B 550 18.00 12.80 14.25 12.00
TCD2B18S21S TM9E026A08MP12 17.5 XAHB24B 550 18.00 12.80 14.25 12.00
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase18
Johnson Controls Ducted Systems

Johnson Controls TCD2B18S21S Specifications

General

Brand	Johnson Controls
Model	TCD2B18S21S
Category	Air Conditioner
Language	English
