Table 23: Cool multiplier furnace - 2 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
Z8ET060A12LMPS1S XAFA24B 0.98 0.90 0.94
Z8ET060A12LMPS1S XAFB24B 0.99 0.92 0.95
Z8ET060A12LMPS1S XAFB30C 1.00 0.95 0.94
Z8ET060A12LMPS1S XAHA24B 0.98 0.90 0.94
Z8ET060A12LMPS1S XAHB24B 0.99 0.92 0.95
Z8ET060A12LMPS1S XAHB30C 1.00 0.94 0.94
Z8ET060A12LMPS1S XAUA24B 0.98 0.90 0.94
Z8ET060A12LMPS1S XAUB30C 1.00 0.95 0.94
Z8ET080B12LMPS1S XAFB24B 1.01 0.98 0.95
Z8ET080B12LMPS1S XAFB30C 1.01 1.00 0.93
Z8ET080B12LMPS1S XAFC30C 1.01 1.00 0.93
Z8ET080B12LMPS1S XAHB24B 1.00 0.97 0.94
Z8ET080B12LMPS1S XAHB30C 1.00 0.98 0.94
Z8ET080B12LMPS1S XAHC30C 1.01 1.00 0.93
Z8ET080B12LMPS1S XAUB30C 1.01 1.00 0.93
Z8ET080C16LMPS1S XAFC30C 1.00 0.95 0.92
Z8ET080C16LMPS1S XAHC30C 1.00 0.94 0.92
Z8ET100C16LMPS1S XAFC30C 1.01 1.02 0.93
Z8ET100C16LMPS1S XAHC30C 1.01 1.01 0.93
Z8ET100C20LMPS1S XAFC30C 0.99 0.91 0.91
Z8ET120C20LMPS1S XAFC30C 0.99 0.91 0.91
Z8ET120C20LMPS1S XAHC30C 0.99 0.91 0.91
Performance data - 2.5 ton
See the following tables for performance and multiplier data for the TCD2B30S21S unit.
Condenser only performance data - 2.5 ton
Table 24: Condenser only performance data - 2.5 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 30.4 1.25 29.0 1.44 27.4 1.63 25.7 1.83 23.8 2.06 21.9 2.31 20.0 2.61
40 118 33.4 1.25 31.9 1.44 30.1 1.63 28.2 1.84 26.3 2.06 24.2 2.32 22.1 2.62
45 130 36.6 1.26 34.9 1.45 33.0 1.64 31.0 1.85 28.9 2.08 26.7 2.33 24.5 2.63
50 142 40.1 1.27 38.2 1.46 36.1 1.66 33.9 1.86 31.6 2.09 29.3 2.35 27.0 2.65
55 156 43.8 1.29 41.6 1.48 39.4 1.68 37.0 1.88 34.6 2.12 32.1 2.38 29.6 2.68
Condenser only performance data notes
• For outdoor unit (condenser) performance only. Data does not include the effects of air handler
power or heat.
• Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves:
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
• Maximum recommended condensing temperature is 140°F.
93Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
