Table 9: Furnace capacity - 2.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B30S21S Z8ET080B12LMPS1S 17.5 XAHB30C 900 28.60 20.80 14.25 12.00
TCD2B30S21S Z8ET080B12LMPS1S 21.0 XAHC30C 900 28.60 20.80 14.25 12.00
TCD2B30S21S Z8ET080B12LMPS1S 21.0 XAHC36D 900 28.60 20.40 14.25 12.00
TCD2B30S21S Z8ET080B12LMPS1S 17.5 XAUB30C 900 28.60 20.80 14.25 12.00
TCD2B30S21S Z8ET080B12LMPS1S 17.5 XAUB36D 900 28.60 20.40 14.25 12.00
TCD2B30S21S Z8ET080C16LMPS1S 21.0 XAFC30C 975 29.20 21.60 14.25 12.00
TCD2B30S21S Z8ET080C16LMPS1S 21.0 XAFC36D 950 29.20 21.20 14.25 12.00
TCD2B30S21S Z8ET080C16LMPS1S 21.0 XAHC30C 950 29.20 21.60 14.25 12.00
TCD2B30S21S Z8ET080C16LMPS1S 21.0 XAHC36D 950 29.20 21.20 14.25 12.00
TCD2B30S21S Z8ET100C16LMPS1S 21.0 XAFC30C 825 28.40 20.00 14.25 12.00
TCD2B30S21S Z8ET100C16LMPS1S 21.0 XAFC36D 800 28.40 19.60 14.25 12.00
TCD2B30S21S Z8ET100C16LMPS1S 21.0 XAHC30C 800 28.40 19.90 14.25 12.00
TCD2B30S21S Z8ET100C16LMPS1S 21.0 XAHC36D 800 28.40 19.60 14.25 12.00
TCD2B30S21S Z8ET100C20LMPS1S 21.0 XAFC30C 1075 29.40 22.60 14.25 12.00
TCD2B30S21S Z8ET100C20LMPS1S 21.0 XAFC36D 1025 29.40 22.00 14.25 12.00
TCD2B30S21S Z8ET100C20LMPS1S 21.0 XAHC30C 1050 29.40 22.40 14.25 12.00
TCD2B30S21S Z8ET100C20LMPS1S 21.0 XAHC36D 1025 29.40 22.00 14.25 12.00
TCD2B30S21S Z8ET120C20LMPS1S 21.0 XAFC30C 900 28.60 20.80 14.00 11.75
TCD2B30S21S Z8ET120C20LMPS1S 21.0 XAFC36D 875 28.60 20.40 14.00 11.75
TCD2B30S21S Z8ET120C20LMPS1S 21.0 XAHC30C 875 28.60 20.80 14.00 11.75
TCD2B30S21S Z8ET120C20LMPS1S 21.0 XAHC36D 850 28.20 20.00 14.00 11.75
Furnace capacity - 3 ton
Table 10: Furnace capacity - 3 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B36S21S TL8E060A12UH11 17.5 XAFB36D 1100 35.60 26.00 13.75 11.25
TCD2B36S21S TL8E060A12UH11 17.5 XAFB36E 1075 35.60 26.00 13.50 11.25
TCD2B36S21S TL8E060A12UH11 17.5 XAUB36D 1100 35.60 26.00 13.75 11.25
TCD2B36S21S TL8E080C16UH11 21.0 XAFC36D 1075 35.60 25.80 14.00 11.75
TCD2B36S21S TL8E080C16UH11 21.0 XAFC42E 1100 35.80 26.20 14.00 11.75
TCD2B36S21S TL8E080C16UH11 24.5 XAFD42E 1100 35.40 26.00 13.75 11.50
TCD2B36S21S TL8E080C16UH11 21.0 XAHC36D 1075 35.60 25.80 14.00 11.50
TCD2B36S21S TL8E080C16UH11 21.0 XAHC42E 1075 35.80 26.00 14.00 11.75
TCD2B36S21S TL8E080C16UH11 24.5 XAHD42E 1075 35.40 25.80 13.75 11.50
TCD2B36S21S TL8E080C16UH11 21.0 XAUC42E 1100 35.80 26.20 14.00 11.75
TCD2B36S21S TL8E100C20UH11 21.0 XAFC36D 1050 35.80 25.60 14.50 12.00
TCD2B36S21S TL8E100C20UH11 21.0 XAFC42E 1050 35.80 25.60 14.50 12.00
TCD2B36S21S TL8E100C20UH11 24.5 XAFD42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S TL8E100C20UH11 21.0 XAHC36D 1025 35.60 25.20 14.25 12.00
TCD2B36S21S TL8E100C20UH11 21.0 XAHC42E 1025 35.60 25.40 14.25 12.00
TCD2B36S21S TL8E100C20UH11 24.5 XAHD42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S TL8E100C20UH11 21.0 XAUC42E 1050 35.80 25.60 14.50 12.00
TCD2B36S21S TL9E060B12UH11 21.0 XAFC36D 1100 35.40 26.00 13.40 11.25
TCD2B36S21S TL9E060B12UH11 21.0 XAFC42E 1100 35.40 26.20 13.40 11.25
TCD2B36S21S TL9E060B12UH11 21.0 XAUC42E 1100 35.40 26.20 13.40 11.25
TCD2B36S21S TL9E080C16UH11 21.0 XAFC36D 1125 35.80 26.20 14.00 11.50
TCD2B36S21S TL9E080C16UH11 21.0 XAFC42E 1125 35.80 26.40 14.00 11.75
TCD2B36S21S TL9E080C16UH11 21.0 XAHC36D 1100 35.60 26.00 14.00 11.50
TCD2B36S21S TL9E080C16UH11 21.0 XAHC42E 1100 35.80 26.20 14.00 11.50
TCD2B36S21S TL9E080C16UH11 21.0 XAUC42E 1125 35.80 26.40 14.00 11.75
TCD2B36S21S TL9E100C20UH11 21.0 XAFC36D 1000 35.40 25.00 14.25 12.00
TCD2B36S21S TL9E100C20UH11 21.0 XAFC42E 1000 35.40 25.00 14.25 12.00
TCD2B36S21S TL9E100C20UH11 21.0 XAHC36D 975 35.20 24.60 14.25 11.75
TCD2B36S21S TL9E100C20UH11 21.0 XAHC42E 975 35.20 24.60 14.25 11.75
TCD2B36S21S TL9E100C20UH11 21.0 XAUC42E 1000 35.40 25.00 14.25 12.00
TCD2B36S21S TM8E040A12MP11 17.5 XAFB36D 1075 35.60 25.80 13.75 11.50
TCD2B36S21S TM8E040A12MP11 17.5 XAFB36E 1075 35.60 25.80 13.75 11.50
TCD2B36S21S TM8E040A12MP11 17.5 XAUB36D 1075 35.60 25.80 13.75 11.50
TCD2B36S21S TM8E060A12MP11 17.5 XAFB36D 1100 35.60 26.00 13.50 11.25
35Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems

Johnson Controls TCD2B18S21S Specifications

General

Brand	Johnson Controls
Model	TCD2B18S21S
Category	Air Conditioner
Language	English
