5. Charge adders shown above do not indicate that coils are rated for every application. Refer
to the Performance data tables for actual performance for specified system matches. Obtain
certified system ratings from http://www.ahridirectory.org.
Charging
1. Check the factory unit charge listed on the unit nameplate to verify the refrigerant charge
for the outdoor unit, the smallest matched indoor unit, and the 15 ft of interconnecting
refrigeration piping.
2. Verify the indoor metering device and additional charge required for the specific matched
indoor unit in the system using Table 4.
3. Add additional charge for the amount of interconnecting refrigeration piping greater than 15
ft at the rate specified in Table 2.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching
indoor unit and actual refrigeration piping length.
5. After weighing in the charge adders for the matched indoor unit and refrigeration piping,
verify the system operation against the temperatures and pressures in the charging chart
for the outdoor unit. Locate the charging charts on the outdoor unit and in the Service Data
Application Guide on www.simplygettingthejobdone.com. Follow the subcool or superheat
charging procedure in the Installation Manual according to the type of indoor metering device
in the system, and allow 10 min after each charge adjustment for the system operation to
stabilize. Record the charge adjustment made to match the charging chart.
6. Permanently stamp the unit nameplate with the total system charge defined as follows: total
system charge = base charge (as shipped) + charge adder for matched indoor unit + charge
adder for actual refrigeration piping length + charge adjustments to match the charging
chart.
Air handler capacity
Table 5: Air handler capacity
Outdoor unit model Air handler model Air handler
width (in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B18S21S JHETB18BBAS2N1 17.5 — 650 18.00 13.30 15.00 12.50
TCD2B18S21S JHVTB18BBAC2N1 17.5 — 725 18.00 13.80 15.00 12.50
TCD2B18S21S JMET08BS2N1 17.5 XAFB18A 725 18.00 13.70 15.00 12.50
TCD2B18S21S JMET08BS2N1 17.5 XAFB24B 725 18.00 13.80 15.00 12.50
TCD2B18S21S JMET08BS2N1 17.5 XAHB24B 700 18.00 13.70 15.00 12.50
TCD2B18S21S JMET12BS2N1 17.5 XAHB24B 650 18.00 13.30 15.00 12.50
TCD2B18S21S JMVT12BC2N1 17.5 XAFB18A 725 18.00 13.80 14.75 12.25
TCD2B18S21S JMVT12BC2N1 17.5 XAFB24B 725 18.00 13.80 15.00 12.50
TCD2B24S21S JHETB18BBAS2N1 17.5 — 725 24.00 16.90 14.75 12.25
TCD2B24S21S JHETB24CBAS2N1 17.5 — 750 24.00 17.30 15.00 12.50
TCD2B24S21S JHVTB18BBAC2N1 17.5 — 775 24.00 17.20 14.75 12.25
TCD2B24S21S JHVTB24CBAC2N1 17.5 — 800 24.00 17.70 15.00 12.50
TCD2B24S21S JMET08BS2N1 17.5 XAFB30C 725 24.00 17.10 15.00 12.50
TCD2B24S21S JMET08BS2N1 17.5 XAHB24B 700 24.00 16.70 14.50 12.25
TCD2B24S21S JMET08BS2N1 17.5 XAHB30C 700 24.00 17.00 15.00 12.50
TCD2B24S21S JMET08BS2N1 17.5 XAUB30C 725 24.00 17.10 15.00 12.50
TCD2B24S21S JMET12BS2N1 17.5 XAFB24B 775 24.00 17.20 14.75 12.25
TCD2B24S21S JMET12BS2N1 17.5 XAFB30C 800 24.00 17.60 15.00 12.50
TCD2B24S21S JMET12BS2N1 17.5 XAHB24B 775 24.00 17.20 14.50 12.25
TCD2B24S21S JMET12BS2N1 17.5 XAHB30C 775 24.00 17.50 15.00 12.50
TCD2B24S21S JMET12BS2N1 17.5 XAUB30C 800 24.00 17.60 15.00 12.50
TCD2B24S21S JMET12CS2N1 21.0 XAFC30C 950 24.00 18.70 15.00 12.50
13Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
