Table 10: Furnace capacity - 3 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B36S21S Z8ES120C20LMPS1 21.0 XAHC42E 1025 35.20 25.20 14.00 11.75
TCD2B36S21S Z8ES120C20LMPS1 24.5 XAHD42E 1025 35.20 25.20 14.00 11.75
TCD2B36S21S Z8ES120C20LMPS1 21.0 XAUC42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S Z8ES120C20SMPS1S 21.0 XAFC36D 1025 35.00 25.00 14.00 11.75
TCD2B36S21S Z8ES120C20SMPS1S 21.0 XAFC42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S Z8ES120C20SMPS1S 24.5 XAFD42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S Z8ES120C20SMPS1S 21.0 XAHC36D 1025 35.00 25.00 14.00 11.75
TCD2B36S21S Z8ES120C20SMPS1S 21.0 XAHC42E 1025 35.20 25.20 14.00 11.75
TCD2B36S21S Z8ES120C20SMPS1S 24.5 XAHD42E 1025 35.20 25.20 14.00 11.75
TCD2B36S21S Z8ES120C20SMPS1S 21.0 XAUC42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S Z8ES130D20LMPS1 24.5 XAFD42E 1175 36.00 26.80 14.25 11.75
TCD2B36S21S Z8ES130D20LMPS1 24.5 XAHD42E 1150 35.80 26.40 14.25 11.75
TCD2B36S21S Z8ES130D20SMPS1S 24.5 XAFD42E 1175 36.00 26.80 14.25 11.75
TCD2B36S21S Z8ES130D20SMPS1S 24.5 XAHD42E 1150 35.80 26.40 14.25 11.75
TCD2B36S21S Z8ET080B12LMPS1S 17.5 XAFB36D 1150 35.40 26.40 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 17.5 XAFB36E 1150 35.60 26.60 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 21.0 XAFC36D 1175 35.40 26.60 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 21.0 XAFC42E 1175 35.80 26.80 13.75 11.50
TCD2B36S21S Z8ET080B12LMPS1S 21.0 XAHC36D 1150 35.40 26.40 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 21.0 XAHC42E 1150 35.60 26.60 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 17.5 XAUB36D 1150 35.40 26.40 13.50 11.25
TCD2B36S21S Z8ET080B12LMPS1S 21.0 XAUC42E 1175 35.80 26.80 13.75 11.50
TCD2B36S21S Z8ET080C16LMPS1S 21.0 XAFC36D 1075 35.40 25.60 14.25 12.00
TCD2B36S21S Z8ET080C16LMPS1S 21.0 XAFC42E 1075 35.60 25.60 14.25 12.00
TCD2B36S21S Z8ET080C16LMPS1S 24.5 XAFD42E 1100 35.60 25.80 14.25 12.00
TCD2B36S21S Z8ET080C16LMPS1S 21.0 XAHC36D 1075 35.40 25.60 14.25 11.75
TCD2B36S21S Z8ET080C16LMPS1S 21.0 XAHC42E 1075 35.60 25.60 14.25 11.75
TCD2B36S21S Z8ET080C16LMPS1S 24.5 XAHD42E 1075 35.60 25.60 14.25 11.75
TCD2B36S21S Z8ET080C16LMPS1S 21.0 XAUC42E 1075 35.60 25.60 14.25 12.00
TCD2B36S21S Z8ET100C16LMPS1S 21.0 XAFC36D 1125 35.40 26.00 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 21.0 XAFC42E 1125 35.60 26.20 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 24.5 XAFD42E 1150 35.60 26.40 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 21.0 XAHC36D 1125 35.40 26.00 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 21.0 XAHC42E 1125 35.60 26.20 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 24.5 XAHD42E 1125 35.60 26.20 14.00 11.75
TCD2B36S21S Z8ET100C16LMPS1S 21.0 XAUC42E 1125 35.60 26.20 14.00 11.75
TCD2B36S21S Z8ET100C20LMPS1S 21.0 XAFC36D 1025 35.00 25.00 14.25 12.00
TCD2B36S21S Z8ET100C20LMPS1S 21.0 XAFC42E 1050 35.40 25.40 14.25 12.00
TCD2B36S21S Z8ET100C20LMPS1S 24.5 XAFD42E 1050 35.40 25.40 14.25 11.75
TCD2B36S21S Z8ET100C20LMPS1S 21.0 XAHC36D 1025 35.00 25.00 14.25 11.75
TCD2B36S21S Z8ET100C20LMPS1S 21.0 XAHC42E 1000 35.00 24.80 14.00 11.75
TCD2B36S21S Z8ET100C20LMPS1S 24.5 XAHD42E 1025 35.20 25.20 14.25 11.75
TCD2B36S21S Z8ET100C20LMPS1S 21.0 XAUC42E 1050 35.40 25.40 14.25 12.00
TCD2B36S21S Z8ET120C20LMPS1S 21.0 XAFC36D 1275 35.80 27.40 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 21.0 XAFC42E 1300 36.00 27.80 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 24.5 XAFD42E 1300 36.00 27.80 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 21.0 XAHC36D 1250 35.80 27.40 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 21.0 XAHC42E 1250 36.00 27.60 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 24.5 XAHD42E 1275 36.00 27.80 13.75 11.50
TCD2B36S21S Z8ET120C20LMPS1S 21.0 XAUC42E 1300 36.00 27.80 13.75 11.50
Furnace capacity - 3.5 ton
Table 11: Furnace capacity - 3.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B42S21S TL8E080C16UH11 21.0 XAFC42E 1225 39.50 29.60 13.75 11.50
TCD2B42S21S TL8E080C16UH11 21.0 XAFC48F 1250 39.50 29.40 13.75 11.50
TCD2B42S21S TL8E080C16UH11 24.5 XAFD42E 1250 40.00 30.00 13.75 11.50
TCD2B42S21S TL8E080C16UH11 24.5 XAFD48F 1250 40.00 29.80 13.75 11.50
TCD2B42S21S TL8E080C16UH11 21.0 XAHC42E 1200 39.50 29.40 13.75 11.50
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase44
Johnson Controls Ducted Systems
