Table 22: Cool multiplier air handler - 2 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
JMVT16CC2N1A XAHC30C 1.01 1.01 0.91
JMVT17CC2N1A XAFC30C 1.01 1.00 0.91
JMVT17CC2N1A XAHC30C 1.01 1.00 0.91
Cool multiplier furnace - 2 ton
Table 23: Cool multiplier furnace - 2 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TL8E060A12UH11 XAFA24B 1.00 0.94 0.94
TL8E060A12UH11 XAFB24B 1.00 0.94 0.94
TL8E060A12UH11 XAFB30C 1.00 0.96 0.92
TL8E060A12UH11 XAHA24B 1.00 0.94 0.94
TL8E060A12UH11 XAHB24B 1.00 0.94 0.94
TL8E060A12UH11 XAHB30C 1.00 0.96 0.94
TL8E060A12UH11 XAUA24B 1.00 0.94 0.94
TL8E060A12UH11 XAUB30C 1.00 0.96 0.92
TL8E080C16UH11 XAFC30C 1.01 0.98 0.93
TL8E080C16UH11 XAHC30C 1.01 0.98 0.93
TL8E100C20UH11 XAFC30C 1.01 1.02 0.93
TL8E100C20UH11 XAHC30C 1.01 1.01 0.93
TL9E060B12UH11 XAFB24B 1.01 0.97 0.95
TL9E060B12UH11 XAFB30C 1.01 0.98 0.95
TL9E060B12UH11 XAFC30C 1.00 0.97 0.94
TL9E060B12UH11 XAHB24B 1.01 0.95 0.97
TL9E060B12UH11 XAHB30C 1.01 0.97 0.95
TL9E060B12UH11 XAHC30C 1.00 0.97 0.94
TL9E060B12UH11 XAUB30C 1.01 0.98 0.95
TL9E080C16UH11 XAFC30C 1.01 0.97 0.93
TL9E080C16UH11 XAHC30C 1.01 0.97 0.93
TL9E100C20UH11 XAFC30C 1.01 1.05 0.93
TL9E100C20UH11 XAHC30C 1.01 1.05 0.95
TM8E040A12MP11 XAFA24B 1.01 0.95 0.95
TM8E040A12MP11 XAFB24B 1.00 0.95 0.94
TM8E040A12MP11 XAFB30C 1.00 0.97 0.92
TM8E040A12MP11 XAHA24B 1.01 0.95 0.95
TM8E040A12MP11 XAHB24B 1.00 0.95 0.94
TM8E040A12MP11 XAHB30C 1.00 0.97 0.92
TM8E040A12MP11 XAUA24B 1.01 0.95 0.95
TM8E040A12MP11 XAUB30C 1.00 0.97 0.92
TM8E060A12MP11 XAFA24B 0.99 0.91 0.93
TM8E060A12MP11 XAFB24B 1.00 0.95 0.94
TM8E060A12MP11 XAFB30C 1.00 0.94 0.92
TM8E060A12MP11 XAHA24B 0.98 0.89 0.92
TM8E060A12MP11 XAHB24B 0.99 0.91 0.93
TM8E060A12MP11 XAHB30C 1.00 0.93 0.92
TM8E060A12MP11 XAUA24B 0.99 0.91 0.93
TM8E060A12MP11 XAUB30C 1.00 0.94 0.92
TM8E080B12MP11 XAFB24B 1.01 0.97 0.95
TM8E080B12MP11 XAFB30C 1.00 0.98 0.92
TM8E080B12MP11 XAFC30C 1.00 0.98 0.92
TM8E080B12MP11 XAHB24B 1.01 0.97 0.95
TM8E080B12MP11 XAHB30C 1.01 0.98 0.95
TM8E080B12MP11 XAHC30C 1.00 0.98 0.92
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase86
