Condenser only performance data - 3 ton
Table 28: Condenser only performance data - 3 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 36.8 1.41 35.2 1.69 33.4 1.94 31.3 2.20 29.1 2.47 26.7 2.77 24.2 3.14
40 118 40.6 1.44 38.8 1.71 36.8 1.96 34.5 2.21 32.0 2.48 29.5 2.78 26.9 3.14
45 130 44.6 1.49 42.6 1.75 40.3 1.99 37.8 2.23 35.2 2.49 32.5 2.79 29.6 3.15
50 142 48.9 1.54 46.6 1.79 44.1 2.03 41.4 2.26 38.5 2.51 35.5 2.81 32.5 3.16
55 156 53.3 1.62 50.8 1.85 48.0 2.07 45.0 2.30 42.0 2.55 38.8 2.84 35.5 3.18
Condenser only performance data notes
• For outdoor unit (condenser) performance only. Data does not include the effects of air handler
power or heat.
• Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves:
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
• Maximum recommended condensing temperature is 140°F.
Cooling performance data - 3 ton
Table 29: Cooling performance data - 3 ton - indoor coil: XAFB36DXXN1
IDCFM 950 1150 1350
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 32.5 36.0 36.0 39.7 42.9 34.4 37.3 37.3 41.0 44.3 36.4 38.6 38.5 42.2 45.7
S.C. 32.5 30.7 26.1 26.3 21.3 34.4 33.8 28.3 28.5 22.9 36.4 36.8 30.6 30.7 24.5
55
kW 2.02 2.02 2.02 2.00 1.99 2.08 2.09 2.09 2.08 2.07 2.15 2.16 2.16 2.15 2.14
T.C. 31.8 34.7 34.9 38.4 42.1 33.7 36.0 36.2 39.7 43.5 35.7 37.2 37.5 41.0 44.8
S.C. 31.8 29.9 25.4 25.7 20.9 33.7 33.0 27.8 28.1 22.7 35.7 36.1 30.3 30.4 24.4
65
kW 2.27 2.27 2.27 2.25 2.23 2.33 2.33 2.34 2.32 2.31 2.39 2.40 2.41 2.39 2.38
T.C. 31.0 33.3 33.8 37.2 41.3 33.0 34.6 35.1 38.5 42.7 35.1 35.9 36.4 39.9 44.0
S.C. 31.0 29.1 24.7 25.2 20.6 33.0 32.2 27.3 27.6 22.5 35.1 35.3 29.9 30.1 24.3
75
kW 2.52 2.51 2.52 2.50 2.48 2.58 2.58 2.59 2.57 2.55 2.64 2.64 2.66 2.64 2.62
T.C. 30.1 32.1 32.4 35.7 39.8 32.1 33.3 33.6 37.0 41.1 34.0 34.5 34.7 38.2 42.4
S.C. 30.1 28.6 24.2 24.6 20.1 32.1 31.6 26.7 27.1 22.0 34.0 34.5 29.1 29.6 23.8
85
kW 2.80 2.80 2.80 2.78 2.77 2.86 2.86 2.87 2.86 2.85 2.93 2.93 2.94 2.93 2.93
T.C. 29.3 30.9 31.0 34.3 38.3 31.1 32.0 32.0 35.4 39.5 32.9 33.1 33.0 36.5 40.7
S.C. 29.3 28.2 23.7 24.0 19.7 31.1 31.0 26.0 26.6 21.5 32.9 33.1 28.3 29.1 23.3
95
kW 3.08 3.08 3.08 3.07 3.07 3.15 3.15 3.15 3.15 3.15 3.22 3.22 3.23 3.22 3.23
T.C. 27.8 29.1 29.2 32.5 36.2 29.5 30.2 30.1 33.5 37.3 31.2 31.3 31.1 34.5 38.5
S.C. 27.8 27.3 22.9 23.4 19.0 29.5 29.7 25.2 25.9 20.7 31.2 31.3 27.4 28.4 22.5
105
kW 3.57 3.59 3.59 3.55 3.53 3.63 3.64 3.65 3.62 3.61 3.68 3.69 3.71 3.69 3.69
T.C. 26.4 27.4 27.4 30.8 34.1 28.0 28.5 28.3 31.7 35.2 29.6 29.6 29.2 32.6 36.3
S.C. 26.4 26.5 22.2 22.8 18.3 28.0 28.4 24.4 25.2 19.9 29.6 29.6 26.6 27.7 21.6
115
kW 4.06 4.09 4.09 4.02 3.98 4.09 4.12 4.14 4.08 4.05 4.13 4.15 4.18 4.14 4.13
Cooling performance data notes
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
105Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
