Table 13: Furnace capacity - 5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B60S21S Z8ES130D20SMPS1S 24.5 XAHD60H 1750 56.00 41.00 13.75 11.50
TCD2B60S21S Z8ES130D20SMPS1S 24.5 XAUD60G 1550 54.50 38.50 13.50 11.50
TCD2B60S21S Z8ES130D20SMPS1S 24.5 XAUD60H 1775 56.00 41.50 13.75 11.50
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAFC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAFC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C16LMPS1S 24.5 XAFD60G 1625 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 24.5 XAFD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAHC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAHC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAHD60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 24.5 XAHD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C16LMPS1S 21.0 XAUC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 24.5 XAUD60G 1625 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C16LMPS1S 24.5 XAUD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAFC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAFC60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C20LMPS1S 24.5 XAFD60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 24.5 XAFD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAHC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAHC60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAHD60G 1575 54.50 38.80 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 24.5 XAHD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET100C20LMPS1S 21.0 XAUC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 24.5 XAUD60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET100C20LMPS1S 24.5 XAUD60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAFC60G 1575 54.50 38.80 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAFC60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET120C20LMPS1S 24.5 XAFD60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 24.5 XAFD60H 1575 54.50 39.00 13.50 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAHC60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAHC60H 1600 55.00 39.50 13.50 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAHD60G 1575 54.50 38.80 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 24.5 XAHD60H 1575 54.50 39.00 13.50 11.25
TCD2B60S21S Z8ET120C20LMPS1S 21.0 XAUC60G 1575 54.50 38.80 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 24.5 XAUD60G 1600 55.00 39.30 13.40 11.25
TCD2B60S21S Z8ET120C20LMPS1S 24.5 XAUD60H 1575 54.50 39.00 13.50 11.25
Furnace capacity data notes
• For rated condition information, see Air handler capacity data notes.
• High-efficiency motor furnaces have blower off delay (BOD) standard.
• PSC furnaces use coil only ratings.
