Johnson Controls TCD2B18S21S User Manual

Table 5: Air handler capacity
Outdoor unit model Air handler model Air handler
width (in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B60S21S JMVT16CC2N1 21.0 XAFC60H 1600 55.50 39.50 14.00 11.75
TCD2B60S21S JMVT16CC2N1 21.0 XAHC60G 1600 55.50 39.00 13.75 11.75
TCD2B60S21S JMVT16CC2N1 21.0 XAHC60H 1600 55.50 39.50 14.00 11.75
TCD2B60S21S JMVT16CC2N1 21.0 XAUC60G 1600 55.50 39.00 13.75 11.75
TCD2B60S21S JMVT17CC2N1 21.0 XAFC60G 1600 55.50 39.00 13.75 11.50
TCD2B60S21S JMVT17CC2N1 21.0 XAFC60H 1600 55.50 39.50 14.00 11.75
TCD2B60S21S JMVT17CC2N1 21.0 XAHC60G 1600 55.50 39.00 13.75 11.75
TCD2B60S21S JMVT17CC2N1 21.0 XAHC60H 1600 55.50 39.50 14.00 11.75
TCD2B60S21S JMVT17CC2N1 21.0 XAUC60G 1600 55.50 39.00 13.75 11.50
TCD2B60S21S JMVT20DC2N1 24.5 XAFD60G 1550 55.50 39.00 14.00 11.75
TCD2B60S21S JMVT20DC2N1 24.5 XAFD60H 1550 55.50 39.00 14.00 11.75
TCD2B60S21S JMVT20DC2N1 24.5 XAHD60G 1550 55.50 39.00 14.00 11.75
TCD2B60S21S JMVT20DC2N1 24.5 XAHD60H 1550 55.50 39.00 14.00 11.75
TCD2B60S21S JMVT20DC2N1 24.5 XAUD60G 1550 55.50 39.00 14.00 11.75
TCD2B60S21S JMVT20DC2N1 24.5 XAUD60H 1550 55.50 39.00 14.00 11.75
Air handler capacity data notes
• Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and
ANSI/AHRI Standard 210/240.
• The cooling MBH is based on 80°F entering air temperature, 50% relative humidity (RH), and
rated airflow.
• The energy efficiency ratio (EER2) is the total cooling output in BTUs at 95°F outdoor ambient
divided by the total electric power in watt-hours at those conditions.
• The seasonal energy efficiency ratio (SEER2) is the total cooling output in BTUs during a normal
annual usage period for cooling divided by the total electric power input in watt-hours during
the same period.
• A cell with no value means not applicable.
Coil only capacity
Table 6: Coil only capacity
Outdoor unit
model
Indoor coil
model
Indoor coil
width (in.)
CFM range Rated CFM Net cool (MBH) Sens cool (MBH) SEER2 EER2
TCD2B18S21S XAFA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
TCD2B18S21S XAFA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
TCD2B18S21S XAFB18A 17.5 450—750 600 18.00 13.20 13.40 11.25
TCD2B18S21S XAFB24B 17.5 450—750 600 18.00 13.30 13.40 11.25
TCD2B18S21S XAHA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
TCD2B18S21S XAHA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
TCD2B18S21S XAHB24B 17.5 450—750 600 18.00 13.30 13.40 11.25
TCD2B18S21S XAUA18A 14.5 450—750 600 18.00 13.20 13.40 11.25
TCD2B18S21S XAUA24B 14.5 450—750 600 18.00 13.30 13.40 11.25
TCD2B24S21S XAFA24B 14.5 600—1000 800 23.80 17.60 13.40 11.25
TCD2B24S21S XAFB24B 17.5 600—1000 800 24.00 17.70 13.40 11.50
TCD2B24S21S XAFB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
TCD2B24S21S XAFC30C 21.0 600—1000 800 24.00 18.10 13.50 11.50
TCD2B24S21S XAHA24B 14.5 600—1000 800 24.00 17.70 13.40 11.50
TCD2B24S21S XAHB24B 17.5 600—1000 800 24.00 17.70 13.40 11.50
TCD2B24S21S XAHB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
TCD2B24S21S XAHC30C 21.0 600—1000 800 24.00 18.10 13.50 11.50
TCD2B24S21S XAUA24B 14.5 600—1000 800 23.80 17.60 13.40 11.25
TCD2B24S21S XAUB30C 17.5 600—1000 800 24.00 18.10 13.50 11.50
TCD2B30S21S XAFA30D 14.5 800—1200 850 28.20 20.20 13.40 11.25
TCD2B30S21S XAFB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase16
Johnson Controls Ducted Systems
