Table 6: Coil only capacity
Outdoor unit
model
Indoor coil
model
Indoor coil
width (in.)
CFM range Rated CFM Net cool (MBH) Sens cool (MBH) SEER2 EER2
TCD2B30S21S XAFB36D 17.5 800—1200 1000 28.80 21.60 13.40 11.25
TCD2B30S21S XAFC30C 21.0 800—1200 1000 28.80 22.00 13.40 11.25
TCD2B30S21S XAFC36D 21.0 800—1200 1000 28.80 21.80 13.40 11.25
TCD2B30S21S XAHB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
TCD2B30S21S XAHC30C 21.0 800—1200 1000 28.80 22.00 13.40 11.25
TCD2B30S21S XAHC36D 21.0 800—1200 1000 28.80 21.60 13.40 11.25
TCD2B30S21S XAUB30C 17.5 800—1200 1000 28.80 22.00 13.40 11.25
TCD2B30S21S XAUB36D 17.5 800—1200 1000 28.80 21.60 13.40 11.25
TCD2B36S21S XAFB36D 17.5 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAFB36E 17.5 1000—1400 1100 35.40 26.20 13.40 11.25
TCD2B36S21S XAFC36D 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAFC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAFD42E 24.5 1000—1400 1150 35.40 26.60 13.40 11.25
TCD2B36S21S XAHC36D 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAHC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAHD42E 24.5 1000—1400 1150 35.40 26.60 13.40 11.25
TCD2B36S21S XAUB36D 17.5 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B36S21S XAUC42E 21.0 1000—1400 1150 35.40 26.40 13.40 11.25
TCD2B42S21S XAFC42E 21.0 1200—1600 1400 40.00 31.40 13.40 11.25
TCD2B42S21S XAFC48F 21.0 1200—1600 1400 41.00 31.80 13.50 11.50
TCD2B42S21S XAFD42E 24.5 1200—1600 1400 41.00 32.20 13.50 11.50
TCD2B42S21S XAFD48F 24.5 1200—1600 1400 41.00 31.80 13.50 11.50
TCD2B42S21S XAHC48F 21.0 1200—1600 1400 41.00 31.80 13.50 11.50
TCD2B42S21S XAHD42E 24.5 1200—1600 1275 40.50 30.80 13.50 11.50
TCD2B42S21S XAHD48F 24.5 1200—1600 1400 41.00 31.80 13.50 11.50
TCD2B42S21S XAUC42E 21.0 1200—1600 1400 40.00 31.40 13.40 11.25
TCD2B42S21S XAUC48F 21.0 1200—1600 1400 41.00 31.80 13.50 11.50
TCD2B48S21S XAFC48F 21.0 1400—1800 1525 47.00 34.20 13.40 11.00
TCD2B48S21S XAFC60G 21.0 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B48S21S XAFD48F 24.5 1400—1800 1525 47.00 34.40 13.40 11.00
TCD2B48S21S XAFD60G 24.5 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B48S21S XAHC48F 21.0 1400—1800 1525 47.00 34.40 13.40 11.00
TCD2B48S21S XAHC60G 21.0 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B48S21S XAHD48F 24.5 1400—1800 1525 47.00 34.40 13.40 11.00
TCD2B48S21S XAHD60G 21.0 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B48S21S XAUC48F 21.0 1400—1800 1525 47.00 34.20 13.40 11.00
TCD2B48S21S XAUC60G 21.0 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B48S21S XAUD60G 24.5 1400—1800 1525 47.50 34.60 13.40 11.00
TCD2B60S21S XAFC60G 21.0 1520—1920 1725 55.50 40.50 13.40 11.00
TCD2B60S21S XAFC60H 21.0 1520—1920 1725 55.50 41.00 13.40 11.00
TCD2B60S21S XAFD60G 24.5 1520—1920 1725 55.50 40.50 13.40 11.00
TCD2B60S21S XAFD60H 24.5 1520—1920 1725 55.50 41.00 13.40 11.00
TCD2B60S21S XAHC60G 21.0 1520—1920 1725 55.50 40.50 13.40 11.00
TCD2B60S21S XAHC60H 21.0 1520—1920 1725 55.50 41.00 13.40 11.00
TCD2B60S21S XAHD60G 21.0 1520—1920 1600 55.50 39.50 13.40 11.00
TCD2B60S21S XAHD60H 24.5 1520—1920 1700 55.50 40.50 13.40 11.00
TCD2B60S21S XAUC60G 21.0 1520—1920 1725 55.50 40.50 13.40 11.00
TCD2B60S21S XAUD60G 24.5 1520—1920 1725 55.50 40.50 13.40 11.00
TCD2B60S21S XAUD60H 24.5 1520—1920 1725 55.50 41.00 13.40 11.00
Coil only capacity data notes
• For rated condition information, see Air handler capacity data notes.
• SEER2: requires a blower time delay unless a standard furnace is equipped with one.
• A cell with no value means not applicable.
• PSC furnaces use coil only ratings.
17Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
