Johnson Controls TCD2B18S21S User Manual

Table 7: Furnace capacity - 1.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B18S21S Z8ET060A12LMPS1S 14.5 XAHA18A 625 18.00 13.20 14.25 12.00
TCD2B18S21S Z8ET060A12LMPS1S 14.5 XAHA24B 625 18.00 13.20 14.50 12.25
TCD2B18S21S Z8ET060A12LMPS1S 17.5 XAHB24B 650 17.90 13.30 14.50 12.25
TCD2B18S21S Z8ET060A12LMPS1S 14.5 XAUA18A 650 18.00 13.30 14.50 12.25
TCD2B18S21S Z8ET060A12LMPS1S 14.5 XAUA24B 625 18.00 13.20 14.50 12.25
TCD2B18S21S Z8ET080B12LMPS1S 17.5 XAFB18A 625 18.00 13.10 14.50 12.25
TCD2B18S21S Z8ET080B12LMPS1S 17.5 XAFB24B 650 18.00 13.30 14.75 12.25
TCD2B18S21S Z8ET080B12LMPS1S 17.5 XAHB24B 625 18.00 13.20 14.50 12.25
Furnace capacity - 2 ton
Table 8: Furnace capacity - 2 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B24S21S TL8E060A12UH11 14.5 XAFA24B 675 23.80 16.50 14.00 12.00
TCD2B24S21S TL8E060A12UH11 17.5 XAFB24B 700 23.80 16.60 14.25 12.00
TCD2B24S21S TL8E060A12UH11 17.5 XAFB30C 700 23.80 16.90 14.50 12.25
TCD2B24S21S TL8E060A12UH11 14.5 XAHA24B 675 23.80 16.50 14.00 12.00
TCD2B24S21S TL8E060A12UH11 17.5 XAHB24B 700 23.80 16.60 14.25 12.00
TCD2B24S21S TL8E060A12UH11 17.5 XAHB30C 700 23.80 16.90 14.50 12.00
TCD2B24S21S TL8E060A12UH11 14.5 XAUA24B 675 23.80 16.50 14.00 12.00
TCD2B24S21S TL8E060A12UH11 17.5 XAUB30C 700 23.80 16.90 14.50 12.25
TCD2B24S21S TL8E080C16UH11 21.0 XAFC30C 725 24.00 17.20 14.75 12.25
TCD2B24S21S TL8E080C16UH11 21.0 XAHC30C 725 24.00 17.20 14.75 12.25
TCD2B24S21S TL8E100C20UH11 21.0 XAFC30C 825 24.00 17.90 14.75 12.25
TCD2B24S21S TL8E100C20UH11 21.0 XAHC30C 800 24.00 17.70 14.75 12.25
TCD2B24S21S TL9E060B12UH11 17.5 XAFB24B 725 24.00 17.00 14.00 12.00
TCD2B24S21S TL9E060B12UH11 17.5 XAFB30C 725 24.00 17.30 14.50 12.00
TCD2B24S21S TL9E060B12UH11 21.0 XAFC30C 725 23.80 17.10 14.50 12.00
TCD2B24S21S TL9E060B12UH11 17.5 XAHB24B 700 24.00 16.80 14.00 11.75
TCD2B24S21S TL9E060B12UH11 17.5 XAHB30C 700 24.00 17.10 14.25 12.00
TCD2B24S21S TL9E060B12UH11 21.0 XAHC30C 725 23.80 17.10 14.25 12.00
TCD2B24S21S TL9E060B12UH11 17.5 XAUB30C 725 24.00 17.30 14.50 12.00
TCD2B24S21S TL9E080C16UH11 21.0 XAFC30C 700 24.00 17.00 14.50 12.25
TCD2B24S21S TL9E080C16UH11 21.0 XAHC30C 700 24.00 17.00 14.50 12.25
TCD2B24S21S TL9E100C20UH11 21.0 XAFC30C 925 24.00 18.50 14.50 12.25
TCD2B24S21S TL9E100C20UH11 21.0 XAHC30C 900 24.00 18.50 14.50 12.00
TCD2B24S21S TM8E040A12MP11 14.5 XAFA24B 700 24.00 16.80 14.25 12.00
TCD2B24S21S TM8E040A12MP11 17.5 XAFB24B 725 23.80 16.80 14.25 12.00
TCD2B24S21S TM8E040A12MP11 17.5 XAFB30C 725 23.80 17.10 14.75 12.25
TCD2B24S21S TM8E040A12MP11 14.5 XAHA24B 700 24.00 16.80 14.25 12.00
TCD2B24S21S TM8E040A12MP11 17.5 XAHB24B 725 23.80 16.80 14.25 12.00
TCD2B24S21S TM8E040A12MP11 17.5 XAHB30C 725 23.80 17.10 14.50 12.25
TCD2B24S21S TM8E040A12MP11 14.5 XAUA24B 700 24.00 16.80 14.25 12.00
TCD2B24S21S TM8E040A12MP11 17.5 XAUB30C 725 23.80 17.10 14.75 12.25
TCD2B24S21S TM8E060A12MP11 14.5 XAFA24B 625 23.60 16.00 14.25 12.00
TCD2B24S21S TM8E060A12MP11 17.5 XAFB24B 725 23.80 16.80 14.25 12.00
TCD2B24S21S TM8E060A12MP11 17.5 XAFB30C 650 23.80 16.50 14.75 12.25
TCD2B24S21S TM8E060A12MP11 14.5 XAHA24B 600 23.40 15.70 14.00 12.00
TCD2B24S21S TM8E060A12MP11 17.5 XAHB24B 625 23.60 16.00 14.25 12.00
TCD2B24S21S TM8E060A12MP11 17.5 XAHB30C 625 23.80 16.30 14.50 12.25
TCD2B24S21S TM8E060A12MP11 14.5 XAUA24B 625 23.60 16.00 14.25 12.00
TCD2B24S21S TM8E060A12MP11 17.5 XAUB30C 650 23.80 16.50 14.75 12.25
TCD2B24S21S TM8E080B12MP11 17.5 XAFB24B 725 24.00 17.00 14.25 12.00
TCD2B24S21S TM8E080B12MP11 17.5 XAFB30C 750 23.80 17.30 14.50 12.25
TCD2B24S21S TM8E080B12MP11 21.0 XAFC30C 750 23.80 17.30 14.50 12.25
TCD2B24S21S TM8E080B12MP11 17.5 XAHB24B 725 24.00 17.00 14.25 12.00
TCD2B24S21S TM8E080B12MP11 17.5 XAHB30C 725 24.00 17.30 14.50 12.00
TCD2B24S21S TM8E080B12MP11 21.0 XAHC30C 750 23.80 17.30 14.50 12.25
TCD2B24S21S TM8E080B12MP11 17.5 XAUB30C 750 23.80 17.30 14.50 12.25
TCD2B24S21S TM8E080C16MP11 21.0 XAFC30C 725 24.00 17.20 14.75 12.25
21Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems

Johnson Controls TCD2B18S21S Specifications

General

Brand	Johnson Controls
Model	TCD2B18S21S
Category	Air Conditioner
Language	English
