Table 33: Cooling performance data - 3.5 ton - indoor coil: XAFC42EXXN1
IDCFM 1200 1400 1600
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 31.1 31.1 30.0 33.6 35.9 32.3 32.1 30.8 34.5 36.3 33.6 33.1 31.6 35.4 36.7
S.C. 31.1 30.9 26.1 26.7 20.7 32.3 32.1 28.2 28.9 22.0 33.6 33.1 30.4 31.1 23.3
115
kW 4.36 4.38 4.44 4.37 4.30 4.43 4.44 4.50 4.44 4.39 4.49 4.49 4.57 4.51 4.47
Cooling performance data notes
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
Multipliers for determining the performance with other
indoor sections
Note: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible
capacity increases by 1060 Btu/h per 1000 CFM per degree above the listed temperature and
decreases by 1060 Btu/h per 1000 CFM per degree below the listed temperature.
Cool multiplier air handler - 3.5 ton
Table 34: Cool multiplier air handler - 3.5 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
— XAFC42E 1.00 1.00 1.00
— XAFC48F 1.02 1.01 1.00
— XAFD42E 1.02 1.03 1.00
— XAFD48F 1.02 1.01 1.00
— XAHC48F 1.02 1.01 1.00
— XAHD42E 1.01 0.98 0.99
— XAHD48F 1.02 1.01 1.00
— XAUC42E 1.00 1.00 1.00
— XAUC48F 1.02 1.01 1.00
JHETC42FBCS2N1 — 1.01 0.97 0.95
JHVTC42FBCC2N1 — 1.00 0.93 0.92
JHVTD42FBCC2N1 — 1.00 0.92 0.92
JMET12CS2N1A XAFC48F 1.01 0.96 0.95
JMET12CS2N1A XAHC48F 1.01 0.96 0.95
JMET12CS2N1A XAUC48F 1.01 0.96 0.95
JMET16CS2N1A XAHC48F 1.05 1.07 0.97
JMET18DS2N1A XAFD42E 1.02 1.04 0.98
JMET18DS2N1A XAFD48F 1.02 1.04 0.98
JMET18DS2N1A XAHD48F 1.02 1.03 0.98
JMVT16CC2N1A XAFC48F 1.00 0.92 0.92
JMVT16CC2N1A XAHC42E 1.00 0.93 0.94
JMVT16CC2N1A XAUC48F 1.00 0.92 0.92
JMVT17CC2N1A XAFC42E 1.00 0.93 0.92
JMVT17CC2N1A XAHC42E 1.00 0.93 0.94
JMVT17CC2N1A XAUC42E 1.00 0.93 0.92
JMVT20DC2N1A XAFD48F 1.00 0.93 0.92
JMVT20DC2N1A XAHD48F 1.00 0.93 0.92
119Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
