Table 43: Cool multiplier furnace - 5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
Z8ET100C20LMPS1S XAHD60G 0.98 0.96 0.96
Z8ET100C20LMPS1S XAHD60H 0.99 0.98 0.97
Z8ET100C20LMPS1S XAUC60G 0.99 0.97 0.97
Z8ET100C20LMPS1S XAUD60G 0.99 0.97 0.97
Z8ET100C20LMPS1S XAUD60H 0.99 0.98 0.97
Z8ET120C20LMPS1S XAFC60G 0.98 0.96 0.96
Z8ET120C20LMPS1S XAFC60H 0.99 0.98 0.97
Z8ET120C20LMPS1S XAFD60G 0.99 0.97 0.97
Z8ET120C20LMPS1S XAFD60H 0.98 0.96 0.96
Z8ET120C20LMPS1S XAHC60G 0.99 0.97 0.97
Z8ET120C20LMPS1S XAHC60H 0.99 0.98 0.97
Z8ET120C20LMPS1S XAHD60G 0.98 0.96 0.96
Z8ET120C20LMPS1S XAHD60H 0.98 0.96 0.96
Z8ET120C20LMPS1S XAUC60G 0.98 0.96 0.96
Z8ET120C20LMPS1S XAUD60G 0.99 0.97 0.97
Z8ET120C20LMPS1S XAUD60H 0.98 0.96 0.96
