4. Name of Parts and Indications for Safety Consideration
6DIHW\ODEHOVDUHDI¿[HGWRWKHLQGRRUXQLWLQRUGHUWRHQVXUHVDIHXVH
Read and understand this manual before using the indoor unit.
Indoor Unit
Air Outlet
Louver
Flat Panel
7KHDLU¿OWHULV
attached inside.)
Wired Controller or
Wireless Controller
(Option)
Location of Indoor Unit Model
Indication
Ɣ It is indicated on the unit nameplate
attached at bottom left.
4.1 Wall Mount Type
4.1.1 TIWM006B21S, TIWM008B21S and TIWM012B21S
Receiver and Indicator
Air Inlet
Electrical Hazard
Located on electrical
box cover.
Front Cover Panel
WARNING Label
Safety Label
Ɣ
Attached to the part indicated by .
WARNING Label
TIMER
FILTER/
DEF RUN
EMERGENCY
Indicator
Receiver
