Turn ON the power supply.
Apply power to unit(s) for approximately 12 hours before operation
in order to preheat the compressor.
'RQRWWXUQ2))WKHPDLQSRZHURIWKHLQGRRUXQLWGXULQJVHDVRQRI
heating or cooling.
1
Press “Mode” switch.
By repeatedly pressing “Mode”
switch, the operation mode
switches in the order of
)$1
, COOL , HEAT ,
DRY
and AUTO .
Above indication is for cooling
operation.
When the unit operation is
stopped, LCD indications of setting
temperature, fan speed and air
ÀRZDQJOHZLOOEHWXUQHG2))DIWHU
10 seconds without pressing the
switches.
Ɣ 5HIHUWR6HFWLRQ³$XWRPDWLF&RROLQJ+HDWLQJ0RGH´IRUDXWRPDWLFFRROLQJ
heating operation mode.
:KHQ95)V\VWHPLVXVHGZLWKZLUHOHVVFRQWUROOHUVIROORZWKHSURFHGXUHDVVKRZQEHORZ
5.2 Wireless Controller (CIR01)
 2SHUDWLRQ0RGH&RROLQJ+HDWLQJ'U\DQG)DQ2SHUDWLRQ
The indoor unit emits a beeping sound when the wireless controller is activated.
NOTE
LCD indications of setting
temperature, fan speed and
DLUÀRZDQJOHDUHWXUQHG21
* Cooling Mode (COOL): To decrease the room temperature.
* Heating Mode (HEAT): To increase the room temperature.
* Dry Mode (DRY): To decrease the humidity in the room.
)DQ0RGH)$1 7RFLUFXODWHWKHDLULQWKHURRP
Function
