4.1.2 TIWM015B21S, TIWM018B21S, TIWM024B21S and TIWM030B21S
Receiver
Indicator
Indoor Unit
Air Outlet
Louver
Flat Panel
7KHDLU¿OWHULV
attached inside.)
Air Inlet
Electrical Hazard
Located on electrical
box cover.
Front Cover Panel
WARNING Label
Safety Label
Ɣ
Attached to the part indicated by .
Wired Controller or
Wireless Controller
(Option)
WARNING Label
Location of Indoor Unit Model
Indication
Ɣ It is indicated on the unit nameplate
attached at bottom left.
Indicator
TIMER FILTER/DEF RUN
