Johnson Controls UNT110-1 User Manual

50
UNT Controller—Unitary (UNT) Controller
R1
Lighting
Rel ay
120 VAC 24 VAC
fcwire
VA1
BINARY INANALOG INPUTS BINARY OUTPUTS
Triac to
Common
Jumper
ANALOG
Fan
Relay
Power
Transformer
120/24 VAC
TE1
RM-T
RM-SP
ON
COM
OFF
AC
COM
IN+
1
2
3
IN
24 VAC
Figure 24: Fan Coil Wiring Example
Table 19: Fan Coil Bill of Materials
Component Part Number
C1 Digital Controller
AS-UNT111-1
TE1 Zone Temperature Sensor
TE-6400/6500 Series
VA1 Valve Actuator
VA-8052 Valve Actuator Assembly
R1 Lighting Relay
GE-RR7
Bill of Materials
