UNT Controller—Unitary (UNT) Controller
Tables 34 and 35 list preconfigured cables and cable components from
Southwest Wire and Windy City Wire. These parts can be ordered through
the Johnson Controls Preferred Supplier Program.
Use Table 34 to order preconfigured cables.
Table 34: Preconfigured Cables
Description Cable Length Southwest Wire
Part Number
Windy City Wire
Part Number
RJ45 Straight-through
Cable Assembly Plenum
7.62 m (25 ft) CBL-STAT25-SW CBL-STAT25-WC
•
Non keyed plugs
15.24 m (50 ft) CBL-STAT50-SW CBL-STAT50-WC
•
0.6 mm diameter
(24 AWG)
22.86 m (75 ft) CBL-STAT75-SW CBL-STAT75-WC
•
8 Conductor
•
Solid Wire
30.48 m (100 ft) CBL-STAT100-SW CBL-STAT100-
WC
Use Table 35 to order cable components for creating your own cables.
Table 35: Cable Components
Description Southwest Wire
Part Number
Windy City Wire
Part Number
304.8 m (1000 ft) Roll of Plenum Rated
•
0.6 mm diameter (24 AWG)
•
8 Conductor
•
Solid Wire
CBL-24/8NAT-SW CBL-24/8NAT-WC
RJ45 Modular Plugs
S100710 S100710
Premium/Economy Crimp Tool
S104012 S104012
Twisted Pair Easy Strip
S104020 S104020
Vendor Code
Numbers
