Johnson Controls UNT110-1 User Manual

UNT Controller—Unitary (UNT) Controller
7
Table 3: Unitary Controller Hardware Characteristics--
Differences
Characteristic UNT110-1 UNT111-1 UNT120-1 UNT121-1 UNT140-1 UNT141-1
Operating
Temperature
Rating
0 to 52°C
(32 to 125°F)
0 to 52°C
(32 to 125°F)
-40 to 52°C
(-40 to 125°F)
-40 to 52°C
(-40 to 125°F)
0 to 52°C
(32 to 125°F)
0 to 52°C
(32 to 125°F)
Analog Outputs:
0 to 10 VDC
@ 10 mA
None 2 None 2 None 2
Binary Outputs:
24 VAC Triacs @
0.5A or 0.8A if
total power is
limited
Low or High side
Common
Selectable
868686
Zone Bus (see
Table 2)
Additional
6-pin Phone
Jack
Additional
6-pin Phone
Jack
I/O Terminations
Quick
Connects
(Spade Lugs)
Quick
Connects
(Spade Lugs)
Quick
Connects
(Spade Lugs)
Quick
Connects
(Spade Lugs)
Fixed Screw
Terminal
Block
Fixed Screw
Terminal
Block
Available
Premounted in
EWC10, with
24 VAC, 50 VA
Transformer
UNT110-101 UNT111-101 UNT140-101 UNT141-101
The UNT complies with the following standards:
● FCC Part 15, Subpart B, Class A
● IEEE 472
● IEEE 587 Category A
● UL 916, UL 864
Standards
Compliance

Johnson Controls UNT110-1 Specifications

General

Brand	Johnson Controls
Model	UNT110-1
Category	Controller
Language	English
