Chapter - General Arrangements
Page Issue 01
OG
1:3
V Range 501 ● 651 ● 801 - Operator’s Guide
Item Component See Chapter
1 Hopper/load compartment -
2 Cowling -
3 Body (hopper and cowl) prop 3
4 Auxiliary engine (VT Only) 6
5 Fuel tank -
6 Hydraulic oil reservoir 6
7 Suction fan case 6
8 Systems locker -
9 Channel brush 6
10 Suction nozzle 6
11 Wide sweep brush 6
12 Wanderhose - optional 4
13 Wanderhose extension tubes -
14 Cab Mounted Controls 2
15 Filter screens 6
16 Wearing plate(s) -
17 Hopper centre baffle - duals only -
18 Intake flaps -
19 Water tank -
20 Water tank filler 6
21 Water tank hydrant filler and filter - nearside 6
22 Water tank drain/flushing valve 6
23 Rear door screen -
24 Rear door drainage tap 3
25 Water tank flushing ports 6
26 Water pump primary suction filter 6
27 Water pump secondary suction filter 6
28 Extended water tank plug 4
29 Water spray jets -
30 Washdown hose and control valve 2
Top Mounted Wanderhose Water control valve - optional 2
Littasnatch Water control valve - optional 2
31 Supawash hose reel and hand lance - optional 4
d Cold Weather Drains
