V Range 501 ● 651 ● 801 - Operator’s Guide
SWEEPING CONTROLS
Symbol ID Description
* Denotes Optional Equipment
* Powascrub; - ON/OFF. Increases Wide Sweep Brush ground pressure to preset
level when on.
F
Pause; - ON/OFF suspends all sweeping and parks brushes. Pressing again
reactivates previous settings.
J
Engine speed; - PULSE/HOLD switch to Increase rpm
Engine speed; - PULSE/HOLD switch to Decrease rpm
I
Water sprays; - ON/OFF Illuminated when selected
Channel brush; - ACTIVE/STOWED
B
Water sprays; - ON/OFF Illuminated when selected
Nozzle; - ACTIVE/STOWED - intake flaps open automatically
A
Water sprays; - ON/OFF Illuminated when selected
Wide Sweep Brush; - ACTIVE/STOWED
C
Gutter spray bars; - ON/OFF
D
+
-
Channel brush speed - PULSE/HOLD switch to Increase rpm
Channel brush speed - PULSE/HOLD switch to Decrease rpm
H
VT - Twin Engine
n/min
ECO Mode Override; - ON/OFF. Allows the engine speed to be increased from
1500 to 2000 rev/min.
G
E
* Powathrust; - ON/OFF. Increases Channel Brush ground pressure to preset level
when on. Without the need to re-adjust the in cab regulator.
VS - Single Engine
n/min
ECO Mode Override; - ON/OFF. Increases the fan to boost when sweeping. ON/
OFF. Activates the fan when using Wanderhose.
G
