Johnston Sweepers Limited
Issue 01
Foreword 4
V Range 501 ● 651 ● 801 - Operator’s Guide
INTERNATIONAL SYMBOLS
Conforming to ISO 3767
Graphical symbols are used to indicate the water, fuel and hydraulic oil tank filler ports and air
cleaner servicing instructions.
Their location and descriptions are shown below.
M02OG-001
1a
1a
2
1b
1b
5
3/4
ULTRA LOW SULFUR
FUEL ONLY
S≤15 mg/kg
1. Water tank filler ports 1a = Hose Pipe
1b = Hydrant
2. Hydraulic oil tank filler
3. Fuel tank (diesel) filler
4. Fuel tank - Engine requires Ultra Low Sulfur fuel
5. Engine air cleaner instructions, i.e. use only genuine Johnston
replacement air cleaner elements and refer to Chapter 6 of this
guide for servicing instructions
All Copyright and rights are the property of Johnston Sweepers Ltd
