JOYTECH SW300DC - 3. Technical Parameters

3
Packing List (Optional)
No.
Name
Quantity
1
Infrared sensor
1
2
0
8
5 6
97
4
1 2 3
Wireless keypad
1
3
Alarm lamp
1
4
Electric lock
1
5
Storage battery
2
Due to the difference of installation environment, our company does not provide the installation
accessories to fix and connect gate openers and wall. Please prepare the these installation accessories
according to actual site situation.
3. Technical Parameters
Model
SW300DC
Power supply
220V/50Hz;110V/60Hz
Motor power
50W
Gate moving speed
18~22s/ 90°
Max.single-leaf weight
300kg
Max.single-leaf length
2.5M
Max.force
2600N
Max.piston stroke
32cm
Remote control distance
≥≥30m
Remote control mode
Single/Four button mode
Storage battery (optional)
DC24V(4.5Ah or 9Ah)
Noise
≤≤58dB
Recording of up remote controls
20pcs
Remote frequency
433.92 MHz
Working temperature
-20°C - +70°C
Package weight
14kg
