7. Direction of Gate Opening
7.1 Gate Opens Inwards
Figure 2
7.2 Gate Opens Outwards
Figure 3
A
B
100mm
120 mm
140 mm
160 mm
180 mm
200 mm
100mm
102°
101°
99°
98°
97°
97°
120mm
111°
108°
106°
104°
103°
99°
140mm
118°
115°
112°
102°
93°
96°
160mm
117°
107°
98°
91°
180mm
103°
96°
90°
200mm
94°
