JOYTECH SW300DC - 4. Installation Drawing; 5. Tools Needed for Standard Installation

4
4. Installation Drawing
Figure 1
SW300DC swing gate opener is applicable to single leaf gate weight less than 300kg, and the length shorter
than 2.5m. The drive mode adopts planetary transmission to combine with the screw rod transmission.
This gate opener must be installed inside the enclosure or yard for protection.
5. Tools Needed for Standard Installation
No.6 Allen
Wrench
Spirit Level
Slotted
Screwdriver
Tape
Phillips
Screwdriver
Adjustable Wrench X
2
Hatching Pen
Note: the cables must be suitable for outdoor use.
