JP-33 SERVICE MANUAL
- -
11
Maintenance Program - Change Chemical
3) Clean processor before adding new chemistry
- Cleaning tanks (Close drain valves)
z With lukewarm water rinse each tank.
z Drain the used water by opening the drain valves.
z Dry all tanks with a lint-free cloth
z Close the drain valve after cleaning all the tanks.
- Cleaning of rack
Important: Do not submerge worm gear in water. Grease from worm gear may loosen
and stick to other parts of rack, also when handling worm gear make sure to not get
grease on other parts of rack.
Soak the three racks in water
separately, or clean each rack with running water while
rotating the worm wheel (gear). Be careful not to damage the roller surface during
cleaning.
- Cleaning of replenishment tanks
Wash out the tanks with lukewarm water. Make sure there are no foreign materials
inside the tanks.
4) Prepare new chemicals
-Please follow chemical manufacturer’s mixing process and guidelines.
5) Filling processor tanks
Important: To prevent cross contamination; make sure to add fixer before developer.
Then with a damp lint-free cloth wipe clean developer tank. Make sure to clean any
fixer residue.
A. Add fixer into the fixer tank by using the pitcher provided with the processor.
- Wash out the measuring cup with running water.
- Fill the fixer tank.
- Pour about 2~2 1/2 pitchers into the tank. Make sure to fill the tank up to overflow
level.
B. Filling developer tank: make sure the tank is clean and the pitcher is thoroughly clean.
To fill developer tank, follow the same method used to fill the fixer tank.
Be careful not to mix the developer and fixer when handling the chemicals.
C. Fill washer tank with water up to overflow level.
