JP-33 SERVICE MANUAL
Technical Support - Parts List
PART VII JP-33 Parts List
JP-33 Parts List for Assembly Section
Issued: Jan. 01. 2005.
No New P/N Description Q'ty Specification
F63-00001
Top Cover Assembly
1 F63-11001 Top Cover
1
HIPS 401AF, Grey color
2 F63-43002 Cushion Sponge for Top-Cover Shield
1
10t 15 x 380, with Glue Tape
3 F63-13018 LCD Window with Glue
1
Acryl w/silk print
4 F63-11004 Button of Control
1
HIPS 401AF with Blue Painting
5 F63-14004A Screw PH Tapping 3 x 10
3
SUS316
6 F63-43004C Rubber Sponge of Door shield
1
Rubber Sponge 20 x 30 x 5t
F63-00002
Bottom Base Assembly
6 F63-11002 Bottom Base
1
HIPS 401AF, Grey color
7 F63-43004 Rubber Sponge for Main-body Shield
1
Rubber Sponge 10 x 380 x 5t
Bottom Nipple Assembly
8 F63-11009 Nipple In A Large type
9
HIPS 401AF, Grey color
9 F63-12029C Nipple of Tank Outlet DEV,FIX,WASH
3
SUS316 φ25 x 20, w/ Pipe φ16
10 F63-14011F Hose Band φ19.5, Ear Clamp 3 SUS 316
11 F63-12029B Nipple of Tank Inlet T type (DEV, FIX)
2
SUS316 φ25 x 20, w/ Pipe φ16, φ8
12 F63-14011F Hose Band φ19.5, Ear Clamp 2 SUS 316
13 F63-14011A Hose Band φ12.8, Ear Clamp
2
SUS316
14 F63-12029D Nipple of Tank Inlet (WASH)
1
SUS316 φ25 x 20, with pipe φ8
15 F63-14011A Hose Band φ12.8, Ear Clamp
1
SUS316
16 F63-12023 Nipple of O/F (Water, DEV, Fix)
3
SUS316 φ30 x 50
17 F63-14022 O-ring A out φ26.5, in φ20 x 2.0t
6
EPDM rubber
18 F63-14014 O-ring C φ24 x 2.4t
9
EPDM rubber
Supporting Bracket Assembly
19 F63-12051 Bracket of Protect Torsion (L)
1
PVC 10 x 10 x 70
20 F63-12052 Bracket of Protect Torsion (S)
1
PVC 10 x 10 x 70
21 F63-12055 Bracket of WASH Rack Mounting
1
ABS 15 x 50 x 100
F63-00007
Main Shaft Assembly
22 F63-11005 Bracket of Main shaft 3 PBT Black
23 F63-12001 Shaft A for Motor drive
1
SUS316 φ8 x 407
24 F63-11006 Warm
3
PBT Black
25 F63-14010 Spring pin for Warm
3
SUS316 φ2.0 x 20
26 F63-14007B Sprocket B (inside hole Φ8)
1
Type No.25 Tooth 19, M4 x 2
27 F63-14006 Wrench Bolt Hex M4 x 8
1
SUS316
28 F63-14004D Screw PH Tapping 4 x 12
6
SUS316
F63-00008
Film Sensor Limit Assembly
29 F63-21021 Reed Switch for Film Sensor Limit
1
LDW-1002, Seo-Il Elec.
30 F63-12037 Bracket of Film Sensor Limit
1
ABS 30 x 30 x 10t
31 F63-43010 Epoxy Glue
1
Epoxy, Araldite 5minute Rapid
32 F63-22022 Heat Tube
2
UL, 3pie x 15
33 F63-22010 Wire 0.26 white for Reed Switch
2
Teflon 0.26pie x 150, White
34 F63-14003 Screw PH M3 x 12
1
SUS316
Wiring
35 F63-23003 Flexible wire w/Connector
1
14wires x 800 w/ Connectors
- -
53
