JP-33 SERVICE MANUAL
36 F63-22010B Wire 1.25 White for Film Sensor
2
Teflon φ1.25, UL
37 F63-14017 Cable Mounted
1
ABS UL
Main PCB Assembly
38 F63-23001 Main PCB Assembly
1
PCB Parts List (ver. 5.0)
39 F63-11013 Case of Main PCB
1
HIPS 401AF, Grey color
40 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
41 F63-11014 Cover of Main PCB Case
1
HIPS 401AF, Grey color
42 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
Terminal Block Assembly
43 F63-21016 Terminal Block
1
250VA 20A KH-6020 10P
44 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
45 F63-12044 Cover of Terminal Block
1
PE Sheet 200 x 200 x 1.5t
46 F63-14004F Screw PH M5 x 10
3
SUS316
47 F63-14004E Screw PH Tapping 4 x 16
1
SUS316
Drain Valve Assembly
48 F63-32003A Drain Valve (Lab Cock Type)
3
Plastic φ10 x 3/8"
49 F63-14009B Hose φ12 x 200, 2m (DEV,FIX,WASH) Red-DEV,Blue-FIX,Clean-WASH
50 F63-43030 Cable Ties 140mm Black
3
PVC UL
Front Nipple Assembly
51 F63-11008 Nipple Out B Small type
3
HIPS 401AF, Grey color
52 F63-11010 Nipple In B Small type
3
HIPS 401AF, Grey color
53 F63-11012 Nipple Nut B Small type
3
HIPS 401AF, Grey color
54 F63-14015 O-ring D φ13 x 2.6t
3
EPDM rubber
55 F63-14016 O-ring E φ15.5 x 2.4t
6
EPDM rubber
56 F63-14017 Cable Mounted for Dummy Cover
3
ABS UL
57 F63-12033A Nipple L type of Drain DEV,FIX,WASH
3
SUS316 φ16.5 x 40
58 F63-12033C Nut of Front Nipple L Type
3
PVC φ16.5
59 F63-14011A Hose Band φ12.8, Ear Clamp
3
SUS316
RPL Pump Assembly
60 F63-21005 RPL Pump for DEV, FIX
2
Iwaki KBR-3XBU3M
61 F63-14004D Screw PH Tapping 4 x 12
4
SUS316
62 F63-22004 Terminal of "O" type
2
O type w/Insulation Cap
63 F63-22013 Wire 1.25 Green for RPL-Pump Wiring
1
Teflon 1.25pie, UL
Solenoid Valve Assembly
64 F63-21010 Solenoid Valve for Water
1
110volt-Siebe, 220volt-PAKER
65 F63-14018 Nipple Φ12 "I" Type for Solenoid
1
Bronze 220volt only
66 F63-12025 Nipple for Wash in-let
1
SUS316 φ26 x 55 220volt only
67 F63-13014 Bracket for Solenoid
1
SUS316 1.6t 200 x 40,
68 F63-14004D Screw PH Tapping 4 x 12
8
SUS316
69 F63-14004F Screw PH M5 x 10
2
SUS316
70 F63-14011A Hose Band φ12.8, Ear Clamp
1
SUS316
71 F63-22012 Wire 1.25 Blue for Sol-Valve Wiring
1
Teflon 1.25pie, UL
Circulation Pump Assembly
72 F63-21009 Circulation Pump
2
Iwaki MD-10
73 F63-14004E Screw PH Tapping 4 x 16
2
SUS316
74 F63-14011F Hose Band φ19.5, Ear Clamp
4
SUS 316
75 F63-12049 Spacer of CIR pump
4
ABS 20 x 20 x 5t
76 F63-12048 Bracket of CIR Hose
2
ABS φ20 x 50
Wring
77 F63-22009 Wire 1.25 Violet for Level Sensor
1
Teflon φ1 x 450, Black
- -
54
