JP-33 SERVICE MANUAL

Technical Support - AC power voltage setting

Part III AC power voltage setting (220V or 240V)

This revision adapt to after Jun 1. 2003. Version 5.01.

Please check and correct the Voltage for the processor, 250V? / 220V? / 240V?

1. New applicant Transformer: see attachment Drawing 1

Before Change) AC In-Put: 110volt, 220volt

After Change)

AC In-Put: 220volt, 240volt

JP-33 of 220voltage field area has dual AC input 220volt, 240volt.

How can use?

- If field AC-voltage is 210volt ~ 240volt: use 220V terminal

- If field AC voltage is 240volt ~ 260volt: use 240V terminal

2. Method of Application Voltage: see attachment Drawing 2

Set voltage

Jump-wire on PCB

Use for 220volt Use for 240volt

“220volt” marking Jump-

wire

Connect a wiring Remove or cut-off a wiring.

“240volt” marking Jump-

wire

Remove or cut-off a

wiring

Connect a wiring

3. Changing method of voltage and discriminate terminal of transformer: see attachment drawing 1.

You can see the printing of part-no or shielding by Plastic Case, this side terminal is for AC

in-put.

4. Reference: 1) Transformer Structure

2) Wiring and Mounting on the main PCB

- -
