JP-33 SERVICE MANUAL
263 F63-11023 Gear B of 1.5" Idle
1
PBT Black
264 F63-11024 Gear-C of 1.5" D-cut
1
PBT Black
265 F63-11025 Gear worm Wheel
1
PBT Black
266 F63-14011D
Hose Band φ12.8, Worm Drive Clamp
3 SUS 316, for Accessory
267 F63-14011E
Hose Band φ22.6, Worm Drive Clamp
6 SUS 316, for Accessory
268 F63-14001 Snap Ring type "C"
12
SUS316 φ7
Hoses Kit in DEV Chemical Tank
269 F63-12012 RPL Pipe with Hose Red, Blue
2
SUS316 φ8 x380, Hose φ8.0 x1m
270 F63-14009C Drain Hose Red, Blue, Clean
3
Hose φ16 x 2meter
271 F63-14009C O/F Hose Red, Blue, Clean
3
Hose φ16 x 2meter
272 F63-14021 Hose Assembly for Water In-let 1 Hose φ15 x 2m, Female coupling
Accessory in FIX Chemical Tank
273 F63-13016 Rack cover for DEV
1 PVC 2.0t 200 x400 "ㄷ" Bending
274 F63-12016 Handle of Rack cover
1
PVC φ10 x 15
275 F63-13015 Rack cover for FIX
1
PVC 2.0t 200 x400 "ㄷ" Bending
276 F63-12016 Handle of Rack cover
1
PVC φ10 x 15
277 F63-32006 Floater of chemical tanks
2
Polycarbonate 150 x 380
278 F63-43008 Beaker
279 F63-31002 I/Manual 1 Printing
280 F63-12053 Bracket Bar for Feed-Tray Under Shield
1
ABS 5 x 5 x 350
281 F63-32001 Tank of DEV, FIX RPL 2 25liter with φ8.5 Hole
282 F63-32004 Stand Table w/ Foot Bolt 1 Aluminum profile w/die-casting
Parts Balance for Optional Requirements
AC Voltage 110volt Requirements
1 F63-12043 Bracket of 110V Sol-Valve 1 SUS316 60 x 60 x 2t
2 F63-14018 Nipple Φ12 "I" Type for Solenoid -1 Bronze 220volt only
3 F63-12025 Nipple for Wash in-let
-1
SUS316 φ26 x 55 220volt only
4 F63-13014 Bracket for Solenoid -1
SUS316 1.6t 200 x 40,
5 F63-14021B Hose for Water In-let 110V 1 Hose φ15 x 2m with Female coupling
6 F63-14021 Hose Assembly for Water In-let -1 Hose φ15 x 2m with Female coupling
7 F63-21018 SSR AC Drive Type (110volt only)
1
AC input to AC output, 40A rating
1 inch Air-Gap Requirements
1 F63-12061 Bracket of 1" Gap Nipple
1
ABS 2t x 20 x 20
2 F63-12062 Bracket of 1" Gap Hose
1
ABS 15 x 15 x 15
2 F63-11007A Nipple Out A Large for 1" Gap
1
HIPS 401AF, Grey color
4 F63-11008A Nipple Out B Small type for 1" Gap
1
HIPS 401AF, Grey color
3 F63-11009A Nipple In A Large type for 1" Gap
1
HIPS 401AF, Grey color
5 F63-14016 O-ring E φ15.5 x 2.4t
1
EPDM rubber
6 F63-14009A Hose of 1" Air-Gap, Clean
1
Silicon Red, Blue, Clean
7 F63-11009 Nipple In A Large type
-1
HIPS 401AF, Grey color/ with Tap
8 F63-12011 Cover of Tank RPL Hole
-1
ABS 3.0t 56 x 100
9 F63-14004C Screw PH Tapping 4 x 10
-1
SUS316 Rack Locker Hole Covering
Desk-Top Requirements
1 F63-12047 Sub Bracket of Desk-Top A
3
PVC φ30 x 40t
2 F63-12047B Sub Bracket of Desk-Top B
1
PVC φ30 x 40t with Slot
Main-Motor Variable Speed Requirements
1 F63-21019
Main Motor (Variable Speed) w/ Gear, Capacitor
1
15W 70 X 70 with Capacitor 1.2uF, VS Sensor
2 F63-21019A Variable Speed Controller 1 Rating 15watt, w/mounting bracket
3 F63-21001 Main Motor w/ Capacitor
-1
15W 70 X 70 with Capacitor 1.2uF
- -
59
